华电技术 ›› 2021, Vol. 43 ›› Issue (12): 29-35.doi: 10.3969/j.issn.1674-1951.2021.12.005

• 节能与环保 • 上一篇    下一篇

火电厂脱硫废水低温烟气蒸发浓缩-主烟道蒸发干燥系统设计及运行

晋银佳1(), 郑长乐2(), 王群奎3(), 宋达3()

  1. 1.华电电力科学研究院有限公司,杭州310030
    2.华电龙口发电股份有限公司,山东 烟台 264000
    3.华电章丘发电有限公司,济南 250200
  • 收稿日期:2021-03-18 修回日期:2021-11-08 出版日期:2021-12-25 发布日期:2021-12-10
  • 作者简介:晋银佳(1986—),男,河南偃师人,高级工程师,博士,从事火电厂给水及废水处理技术研究与应用工作(E-mail: 757107023@qq.com)。
    郑长乐(1984—),男,山东龙口人,工程师,硕士,从事火电化水及水处理系统运行维护管理工作(E-mail: 598398667@qq.com)。
    王群奎(1978—),男,山东潍坊人,高级工程师,从事火电厂给水及废水处理技术研究与应用工作(E-mail: 58522181@qq.com)。
    宋达(1988—),男,内蒙古赤峰人,工程师,硕士,从事火电化水及水处理系统运行维护管理工作(E-mail: 164651805@qq.com)。
  • 基金资助:
    国家重点研发计划项目(2016YFC0203704-2);国家重点研发计划项目(2017YFB0603201-03)

Design and operation of the low-temperature flue gas evaporation-main flue duct drying system for desulfurization wastewater treatment in coal-fired power plants

JIN Yinjia1(), ZHENG Changle2(), WANG Qunkui3(), SONG Da3()

  1. 1. Huadian Electric Power Research Institute Company Limited, Hangzhou 310030, China
    2. Huadian Longkou Power Generation Company Limited, Yantai 264000, China
    3. Huadian Zhangqiu Power Generation Company Limited, Jinan 250200, China
  • Received:2021-03-18 Revised:2021-11-08 Online:2021-12-25 Published:2021-12-10

摘要:

利用低温烟气热量对脱硫废水进行蒸发浓缩和蒸发干燥,从而实现脱硫废水的零排放处理,具有系统简单、投资运行成本低、维护工作量小等优点。脱硫废水低温烟气蒸发浓缩系统和主烟道蒸发干燥系统的运行效果和运行稳定性受废水水质、机组负荷、烟气温度、烟气流场等因素的影响,需要根据项目的实际情况进行优化。根据某300 MW燃煤机组的烟气参数和脱硫废水水质水量情况,对脱硫废水烟气蒸发浓缩系统和主烟道蒸发干燥系统进行了优化设计。系统性能测试结果表明,低温烟气蒸发浓缩处理装置平均处理废水量为10.44 m³/h,浓缩减量后的浓水水量平均为0.96 m³/h,主烟道蒸发干燥装置平均处理废水量为1.5 m³/h,相关指标满足系统设计要求。

关键词: 火电厂, 零排放, 脱硫废水, 低温烟气, 主烟道, 蒸发浓缩, 蒸发干燥

Abstract:

Evaporating and drying desulfurization wastewater by waste heat from low-temperature flue gas can realize zero liquid discharge of desulfurization wastewater, which is of advantages of simple structure, low investment and operation cost, and little maintenance work. The operation performance of a low-temperature flue gas evaporation-main flue duct drying system depends on wastewater characteristics, unit load, flue gas temperature, flue gas flow field and other factors,which should be optimized according to the actual operation condition. The low-temperature flue gas evaporation-main flue duct drying system of a 300 MW coal-fired unit was optimized according to its flue gas parameters and wastewater characteristics. The performance test results show that the flue gas evaporation and condensation system can process 10.44 m³/h wastewater; the concentrated water flow is 0.96 m³/h on average; and the main flue duct evaporation system can process 1.56 m³/h wastewater on average. The relative operation parameters meet the design requirement of the system.

Key words: thermal power plant, zero discharge, desulfurization wastewater, low-temperature flue gas, main flue duct, evaporative concentration, evaporative drying
