“双碳”目标下传统火电面临的挑战与对策

doi:10.3969/j.issn.1674-1951.2021.12.006

摘要/Abstract

摘要：

“双碳”目标下,电力行业的低碳发展面临严峻挑战。通过梳理国外碳中和目标及采取的路径和措施,结合我国“双碳”目标及预期路径,分析了传统火电企业面临的可再生能源消纳、传统火电退役困难等问题。传统火电结合储能技术可提升灵活性,满足电力系统运行的稳定性;传统火电可融合化工产业及碳捕获、利用与封存（CCUS）技术等构建火电新型产业链。传统火电转型发展关乎国家能源安全与民生保障,在可再生能源快速发展过程中应克服新能源消纳和储能障碍,同时,火电的兜底作用和基荷作用不可忽视。

关键词: 温室气体排放, “双碳”目标, 火电, 储能技术, CCUS, 新型电力系统, 多能耦合, 可再生能源

Abstract:

To achieve the goals of carbon neutrality and carbon peak,there are stern challenges confronted by power industry in its low-carbon transformation. Combing the goals and countermeasures taken by foreign countries and regions,the difficulties faced by traditional thermal power enterprises in renewable energy consumption and old unit decommissioning are analyzed. Combination traditional thermal power plants with energy storage technology can enhance their operation flexibility and stabilize the whole power system. Integrating traditional thermal power with chemical industry, CCUS and other new technologies can build a new thermal power industry chain. The transformation and development of traditional thermal power is related to national energy security and people's livelihood. Thus,in the rapid development of renewable energy, the obstacles of new energy consumption and energy storage should be overcome, and the role of thermal power as safeguard and base load is unignorable.

Key words: greenhouse gas emission, the target of carbon neutrality and carbon peaking, thermal power, energy storage technology, CCUS, new power system, multi-energy coupling, renewable energy

中图分类号:

TK01⁺9

马双忱, 杨鹏威, 王放放, 樊帅军, 赵光金, 李琦, 袁文玺, 卢锐, 邱明杰. “双碳”目标下传统火电面临的挑战与对策[J]. 综合智慧能源, 2021, 43(12): 36-45.

MA Shuangchen, YANG Pengwei, WANG Fangfang, FAN Shuaijun, ZHAO Guangjin, LI Qi, YUAN Wenxi, LU Rui, QIU Mingjie. Challenges and countermeasures of traditional thermal power under the goals of carbon neutrality and carbon peaking[J]. Integrated Intelligent Energy, 2021, 43(12): 36-45.

图/表 10

表1

图1

图2

表2

表3

图3

图4

图5

图6

图7

参考文献 72

[1]	屈博, 刘畅, 李德智, 等. “碳中和”目标下的电能替代发展战略研究[J]. 电力需求侧管理, 2021, 23(2):1-3,9.
	QU Bo, LIU Chang, LI Dezhi, et al. Research on the development strategy of electricity substitution under the target of "carbon neutral"[J]. Power Demand Side Management, 2021, 23(2):1-3,9.
[2]	国家统计局. 中华人民共和国2019年国民经济和社会发展统计公报[J]. 今日工程机械, 2020(1):16-18.
[3]	国际能源署. 2019年全球碳排放报告[R]. 2020.
[4]	侯艳峰. 燃煤-捕碳机组热力系统优化研究[D]. 北京:华北电力大学, 2016.
[5]	POLLITTH Hector. 分析：在2060 年实现“碳中和” 可使我国“更富足”[R/OL]. （ 2020-09-29）[2021-10-29]. https://www.carbonbrief.org/https-www-carbonbrief-org-2060-tan-zhong-he-ke-shi-zhong-guo-geng-fu-zu
[6]	刘继生基于综合物探的矿井采空区探测技术研究[J]. 中国化工贸易, 2020, 12(30):101,103.
[7]	姜克隽. IPCC 1.5 ℃特别报告发布,温室气体减排新时代的标志[J]. 气候变化研究进展, 2018, 14(6):640-642.
	JIANG Kejuan. IPCC special report on 1.5 ℃ warming: A starting of new era of global mitigation[J]. Climate Change Research, 2018, 14(6):640-642.
[8]	IPCC special report global warming of 1.5 ℃[J]. Energy focus, 2018, 35(3):10-11.
[9]	Special report on global warming[J]. Fuel Oil News, 2018, 83(11):36-37.
[10]	王涵宇, 吴思萱, 张扬清, 等. 德国推进碳中和的路径及对我国的启示[J]. 可持续发展经济导刊, 2021(3):27-30.
	WANG Hanyu, WU Sixuan, ZHANG Yangqing, et al. The path of carbon neutral in Germany and its enlightenment to China[J]. Carbon Neutral, 2021(03):27-30.
[11]	龙云. 法国低碳能源转型战略研究[J]. 海峡科技与产业, 2020(10):10-13.
[12]	杜群, 李子擎国外碳中和的法律政策和实施行动[J]. 中国环境报, 2021-04-16（6）.
[13]	段晓男, 曲建升, 曾静静, 等. 《京都议定书》缔约国履约相关状况及其驱动因素初步分析[J]. 世界地理研究, 2016, 25(4):8-16.
	DUAN Xiaonan, QU Jiansheng, ZENG Jingjing, et al. Preliminary analysis on the carbon reduction performance and its driving factors based on the Kyoto protocol goals for annex I countries[J]. World Regional Studies, 2016, 25(4):8-16.
[14]	曾文革, 周钰颖. 论《京都议定书》第二期承诺对国家发展权的保障及其局限性[J]. 东南大学学报(哲学社会科学版), 2013, 15(3):42-48.
[15]	李威. 从《京都议定书》到《巴黎协定》:气候国际法的改革与发展[J]. 上海对外经贸大学学报, 2016(5):62-73,84.
	LI Wei. From "Kyoto Protocol" to "Paris Agreement": The reform and development of international climate law[J]. Journal of Shanghai University of International Business and Economics, 2016(5):62-73,84.
[16]	SANTOS S, DIXON T. CCS in CDM mechanisms. IEA Greenhouse Gas R&D Programme[C]. Indonesia:CCOP-EPPM Workshop, 2012.
[17]	许明珠. 澳大利亚碳市场机制设计[J]. 世界环境, 2012(2):56-57.
	XU Mingzhu. The design of Australian carbon market mechanism[J]. World Environment, 2012(2):56-57.
[18]	樊威. 澳大利亚碳市场执法监管体系对我国的启示[J]. 科技管理研究, 2020, 40(8):267-274.
	FAN Wei. The enlightenment of Australian carbon market law enforcement supervision system to China[J]. Science and Technology Management Research, 2020, 40(8):267-274.
[19]	栾晶. 英国《气候变化法案》研究及其启示[D]. 济南:山东师范大学, 2011.
[20]	郑爽. 全国碳交易体系监管制度研究[J]. 中国能源, 2018, 40(11):17-20.
[21]	王志峰, 何雅玲, 康重庆, 等. 明确太阳能热发电战略定位促进技术发展[J]. 华电技术, 2021, 43(11):1-4.
	WANG Zhifeng, HE Yaling, KANG Chongqing, et al. Strategic positioning of solar thermal power generation to promote technological progress[J]. Huadian Technology, 2021, 43(11):1-4.
[22]	One NYC 2050 building a strong and fair city. New York City's green new deal[EB/OL]. （ 2019-05-01）[2021-10-07]. http://onenyc.cityofnewyork.us/strategies/onenyc-2050
[23]	郝晓地, 魏静, 曹亚莉. 美国碳中和运行成功案例——Sheboygan污水处理厂[J]. 中国给水排水, 2014, 30(24):1-6.
	HAO Xiaodi, WEI Jing, CAO Yali. A successful case of carbon-neutral operation in America: Sheboygan WWTP[J]. China Water & Wastewater, 2014, 30(24):1-6.
[24]	FORCE J. Encouraging energy efficiency in US wastewater treatment[J]. Water21, 2009(6):32-34.
[25]	洪志超, 苏利阳. 国外城市碳中和策略及对我国的启示[J]. 环境保护, 2021, 49(16):68-71.
	HONG Zhichao, SU Liyang. The carbon neutral strategy of city in international and its implication to China[J]. Environmental Protection, 2021, 49(16):68-71.
[26]	City of Adelaide. 2020—2024 Strategic Plan： The most liveable city in the world[EB/OL]. （ 2020-11-05）[2021-11-05]. https://www.cityofadelaide.com.au/about-adelaide/research-statistics/wellbeing-indicators/ .
[27]	王灿, 张雅欣. 碳中和愿景的实现路径与政策体系[J]. 中国环境管理, 2020, 12(6):58-64.
	WANG Can, ZHANG Yaxin. Implementation pathway and policy system of carbon neutrality vision[J]. Chinese Journal of Environmental Management, 2020, 12(6):58-64.
[28]	郭伟, 唐人虎. 2060碳中和目标下的电力行业[J]. 能源, 2020(11):19-26.
[29]	电力规划设计总院. 我国能源发展报告2019 [R]. 2020.
[30]	李芸. 含大规模可再生能源的电力系统可靠性评估[D]. 银川:宁夏大学, 2020.
[31]	郭琦, 郭海平, 朱益华, 等. 可再生能源灵活消纳的数字物理智能决策平台研发及应用[Z]. 南方电网科学研究院有限责任公司, 2019.
[32]	MELLO G, DIAS M F, ROBAINA M. Wind farms life cycle assessment review: CO₂ emissions and climate change[J]. Energy Reports, 2020, 6(S8):214-219.
[33]	陈伟, 陈键. 消纳弃风电的风电供热系统经济性与设计[J]. 煤气与热力, 2020, 40(8):1-3.
	CHEN Wei, CHEN Jian. Heat source and cold source economy and design of wind power heating system for consuming abandoned wind power[J]. Gas & Heat, 2020, 40(8):1-3.
[34]	魏海姣, 鹿院卫, 张灿灿, 等. 燃煤机组灵活性调节技术研究现状及展望[J]. 华电技术, 2020, 42(4):57-63.
	WEI Haijiao, LU Yuanwei, ZHANG Cancan, et al. Status and prospect of flexibility regulation technology for coal-fired power plants[J]. Huadian Technology, 2020, 42(4):57-63.
[35]	吴厦成, 官思发, 吴洲钇, 等. 低碳背景下能源系统安全不容忽视——美国德州、英国伦敦停电事故反思[J]. 产业与科技论坛, 2021, 20(9):67-69.
[36]	朱法华, 王玉山, 徐振, 等. 我国电力行业碳达峰、碳中和的发展路径研究[J]. 电力科技与环保, 2021, 37(3):9-16.
	ZHU Fahua, WANG Yushan, XU Zhen, et al. Research on the development path of carbon peak and carbon neutrality in China's Power Industry[J]. Electric Power Technology and Environmental Protection, 2021, 37(3):9-16.
[37]	HEPTONSTALL P J, GROSS R J K. A systematic review of the costs and impacts of integrating variable renewables into power grids[J]. Nature Energy, 2020, 6(1):72-83. doi: 10.1038/s41560-020-00695-4
[38]	夏丽娟, 苏艳萍, 王垂涨. 碳达峰碳中和背景下可再生能源发电环境保护问题探析[J]. 低碳世界, 2021, 11(6):125-126.
[39]	胡鞍钢. 我国实现2030年前碳达峰目标及主要途径[J]. 北京工业大学学报(社会科学版), 2021, 21(3):1-15.
	HU Angang. China's goal of achieving carbon peak by 2030 and its main approaches[J]. Journal of Beijing University of Technology(Social Sciences Edition), 2021, 21(3):1-15.
[40]	高虎. 2019年我国非化石能源发展形势分析及未来发展展望[J]. 中国能源, 2020, 42(3):4-8.
[41]	孙旭东, 张蕾欣, 张博. 碳中和背景下我国煤炭行业的发展与转型研究[J]. 中国矿业, 2021, 30(2):1-6.
	SUN Xudong, ZHANG Leixin, ZHANG Bo. Research on the coal industry development and transition in China under the background of carbon neutrality[J]. China Mining Magazine, 2021, 30(2):1-6.
[42]	李政, 陈思源, 董文娟, 等. 现实可行且成本可负担的我国电力低碳转型路径[J]. 洁净煤技术, 2021, 27(2):1-7.
	LI Zheng, CHEN Siyuan, DONG wenjuan, et al. Feasible and affordable pathways to low-carbon power transition in China[J]. Clean Coal Technology, 2021, 27(2):1-7.
[43]	Climate action tracker. China going carbon neutral before 2060 would lower warming projections by around 0.2 to 0.3 degrees C[EB/OL]. （ 2020-09-23）[2021-11-05]. https://climateanalytics.org/latest/china-going-carbon-neutral-before-2060-would-lower-warming-projections-by-around-02-to-03-degrees-c/
[44]	孙韶华, 王璐, 白涌泉, 等拉闸限电的背后：煤炭价格高企火电企业发电意愿低迷[J]. 企业家日报, 2021-09-29（3）.
[45]	水电水利规划设计总院. 中国可再生能源发展报告2020[M]. 北京: 中国水利水电出版社, 2017(3),2021.
[46]	康重庆, 姚良忠, 朱凌志, 等. 如何规划和运行含高比例可再生能源的未来电力系统[J]. 科技纵览, 2020(6):56-64.
[47]	孙玉树, 杨敏, 师长立, 等. 储能的应用现状和发展趋势分析[J]. 高电压技术, 2020, 46(1):80-89.
	SUN Yushu, YANG Min, SHI Changli, et al. Analysis of application status and development trend of energy storage[J]. High Voltage Engineering, 2020, 46(1):80-89.
[48]	张文建, 崔青汝, 李志强, 等. 电化学储能在发电侧的应用[J]. 储能科学与技术, 2020, 9(1):287-295.
	ZHANG Wenjian, CUI Qingru, LI Zhiqiang, et al. Application of electrochemical energy storage in power generation[J]. Energy Storage Science and Technology, 2020, 9(1):287-295.
[49]	李先锋, 张洪章, 郑琼. 能源革命中的电化学储能技术[J]. 我国科学院院刊, 2019, 34(4):443-449.
	LI Xianfeng, ZHANG Hongzhang, ZHENG Qiong. Electrochemical energy storage technology in energy revolution[J]. Bulletin of Chinese Academy of Sciences, 2019, 34(4):443-449.
[50]	黄博文. 储能应用领域与场景综述[J]. 大众用电, 2020, 35(10):19-20.
[51]	丁玉龙, 来小康, 陈海生, 等. 储能技术及应用[M]. 北京: 化学工业出版社, 2018.
[52]	魏书洲, 李兵发, 孙晨阳, 等. 压缩空气储能技术及其耦合发电机组研究进展[J]. 华电技术, 2021, 43(7):9-16.
	WEI Shuzhou, LI Bingfa, SUN Chenyang, et al. Research progress of compressed air energy storage and its coupling power generation[J]. Huadian Technology, 2021, 43(7):9-16.
[53]	张婷. 分布式蓄热在集中供热系统中的应用研究[D]. 2017.
[54]	华电电力科学研究院. 一种利用熔融盐蓄热实现电站调峰的装置：CN201720780491.5[P]. 2018-02-23.
[55]	赵长颖, 闫君, 赵耀. 如何实现媲美化石能源的大规模储能技术?[J]. 上海交通大学学报, 2021, 55(z1):91-92.
	ZHAO Changying, YAN Jun, ZHAO Yao. How to develop Large-scale energy storage technologies comparable to fossil fuels?[J]. Journal of Shanghai Jiaotong University, 2021, 55(z1):91-92.
[56]	ZHAO Y, ZHAO C Y, MARKIDES C N, et al. Medium-and high-temperature latent and thermochemical heat storage using metals and metallic compounds as heat storage media: A technical review[J]. Applied Energy, 2020, 280:115950. doi: 10.1016/j.apenergy.2020.115950
[57]	DUMONT O, FRATE G F, PILLAI A, et al. Carnot battery technology: A state-of-the-art review[J]. Journal of Energy Storage, 2020, 32.
[58]	刘金朋, 侯焘. 氢储能技术及其电力行业应用研究综述及展望[J]. 电力与能源, 2020, 41(2):230-233,247.
	LIU Jinpeng, HOU Xi. Review and prospect of hydrogen energy storage technology and its application in power industry[J]. Power & Energy, 2020, 41(2):230-233,247.
[59]	SURYANTO B H R, DU H L, WANG D, et al. Challenges and prospects in the catalysis of electroreduction of nitrogen to ammonia[J]. Nature Catalysis, 2019, 2(4):290-296. doi: 10.1038/s41929-019-0252-4
[60]	葛睿, 胡旭, 董灵玉, 等. 电化学耦合阴极二氧化碳还原与阳极氧化合成[J]. 化工进展, 2021, 40(9):5132-5144.
	GE Ruin, HU Xu, DONG Lingyu, et al. Electrochemical coupling between cathodic carbon dioxide reduction and anodic oxidation synjournal[J]. Chemical Industry and Engineering Progress, 2021, 40(9):5132-5144.
[61]	张丹彤. 光/电催化二氧化碳还原的过渡金属纳米材料制备及构效关系研究[D]. 长春:吉林大学, 2021.
[62]	JIANG K, ASHWORTH P. The development of carbon capture utilization and storage (CCUS) research in China: A bibliometric perspective[J]. Renewable and Sustainable Energy Reviews, 2021, 138.
[63]	宋微, 张永春, 陈绍云. 化学溶剂法吸收二氧化碳试剂综述[C]// 二氧化碳减排与捕集、封存及绿色化利用研讨会论文集. 2009:114-119.
[64]	申硕, 樊静丽, 陈其针, 等. 碳捕集、利用与封存(CCUS)技术的文献计量分析[J]. 热力发电, 2021, 50(1):47-53.
	SHEN Shuo, FAN Jingli, CHEN Qizhen, et al. Bibliometric analysis of carbon capture, utilization and storage technology[J]. Thermal Power Generation, 2021, 50(1):47-53.
[65]	The global status of CCS 2019[R]. Australia： Globe CCS Institute, 2019.
[66]	张瑞. 有机胺溶剂化学结构与二氧化碳吸收-解吸性能构效关系的探究[D]. 长沙:湖南大学, 2018.
[67]	DIAO Y F, ZHENG X Y, HE B S, et al. Experimental study on capturing CO₂ greenhouse gas by ammonia scrubbing[J]. Energy Conversion and Management, 2003, 45(13-14):2283-2296. doi: 10.1016/j.enconman.2003.10.011
[68]	CAI T, SUN H B, QIAO J, et al. Cell-free chemoenzymatic starch synjournal from carbon dioxide[J]. Science, 2021, 373(6562):1523-1527. doi: 10.1126/science.abh4049
[69]	刘牧心, 梁希, 林千果, 等. 碳中和驱动下CCUS项目衔接碳交易市场的关键问题和对策分析[J]. 中国电机工程学报, 2021, 41(14):4731-4739.
	LIU Muxin, LIANG Xi, LIN Qianguo, et al. Key issues and countermeasures of CCUS projects linking carbon emission trading market under the target of carbon neutrality[J]. Proceedings of the CSEE, 2021, 41(14):4731-4739.
[70]	岳良. 烧结烟气脱硫系统流场数值分析与实验研究[D]. 武汉:华中科技大学, 2011.
[71]	邢晨健, 钱煜, 周燃, 等. 太阳能聚光光伏-余热碳捕集利用方式分析[J]. 华电技术, 2020, 42(4):84-88.
	XING Chenjian, QIAN Yu, ZHOU Ran, et al. Analysis of utilization modes combining concentrating photovoltaic power generation and photovoltaic residual heat driving carbon capture[J]. Huadian Technology, 2020, 42(4):84-88.
[72]	毛健雄. 燃煤耦合生物质发电[J]. 分布式能源, 2017, 2(5):47-54.
	MAO Jianxiong. Co-firing biomass with coal for power generation[J]. Distributed Energy, 2017, 2(5):47-54.

碳中和时间	正在立法	立法规定	承诺
2035年			芬兰
2040年			奥地利、冰岛
2045年		瑞典
2050年	欧盟、加拿大、韩国、西班牙、智利、斐济	英国、法国、丹麦、新西兰、匈牙利	日本、德国、瑞士、挪威、爱尔兰、南非、葡萄牙、哥斯达黎加、斯洛文尼亚、马绍尔群岛、美国

储能技术类型	成熟度	投资成本/（元·kW^-1）	转化效率/%
抽水储能	商业化	5 000~6 000	71~80
压缩空气	示范项目	3 000~5 500	42~75

方案	优点	缺点
热电联产机组配热水储热灵活调峰^[53]	技术相对成熟、改造范围较小、耦合情况好	空间使用较大、储热时运行负荷大、夜间和极端天气需辅助加热
纯凝机组配高温熔盐储热系统灵活性调峰^[34]	性能良好、系统运行压力小、温度范围较宽、储热量大、价格低、储热密度大	熔盐管路容易发生凝固或冻堵;熔盐对管道和储罐腐蚀性强;极端天气下需要采取防冻措施
