面向高耗能企业铝加工过程的节能减碳潜力评价及画像研究

doi:10.3969/j.issn.2097-0706.2024.08.001

摘要/Abstract

摘要：

为引导高耗能企业实施可持续发展战略，促进碳减排和能源效率提升，以高耗能企业中铝加工过程为例，考虑能效、碳排放和环境多维指标，建立节能减碳评价指标体系，以确保评估的全面性和准确性。运用层次分析法对铝加工过程中的各加工工段的效能、碳排放水平和环境影响进行评估。在评估过程中，结合具体企业案例，对其各加工工段的节能减碳潜力情况进行详细分析，并对节能减碳评价指标体系进行了敏感性分析，确保建立的节能减碳潜力评价指标体系的普适性。结果表明：铝加工企业可以从熔铸工段开始，提升其节能减碳能力。通过用户画像分析，提出优化生产过程等建议，减少能源消耗和环境污染，实现可持续发展目标。

关键词: 高耗能企业, 铝加工过程, 节能减碳潜力, 层次分析法, 用户画像

Abstract:

To realize the sustainable development of high-energy-consuming enterprises， and promote carbon emission reduction and energy efficiency， an energy-saving and carbon-reduction evaluation index system for aluminum processing is established. The system takes energy efficiency， carbon emission and environment indicators into considerations， so as to ensure the comprehensiveness and accuracy of the evaluation. The analytic hierarchy process is used to evaluate the efficiency， carbon emission level and environmental impact of each processing section in aluminum processing. In a case study， the energy-saving and carbon-reduction potential of each processing section was evaluated， and the sensitivity analysis on the energy-saving and carbon-reduction evaluation index system was carried out to ensure the universality of the established index system. The results show that aluminum processing enterprises can improve their energy-saving and carbon-reduction capabilities from updating the casting process. Based on user profiling， optimizing suggestions for production process are proposed to reduce energy consumption and environmental pollutants，achieving sustainable development goals.

Key words: high-energy-consuming enterprise, aluminum processing, energy saving and carbon reduction potential, analytic hierarchy process, user profile

中图分类号:

TK09

罗玉伶, 彭道刚, 赵慧荣, 渠博岗. 面向高耗能企业铝加工过程的节能减碳潜力评价及画像研究[J]. 综合智慧能源, 2024, 46(8): 1-11.

LUO Yuling, PENG Daogang, ZHAO Huirong, QU Bogang. Evaluation on energy-saving and carbon-reduction potential of aluminum processing in high-energy-consuming enterprises and their profiles[J]. Integrated Intelligent Energy, 2024, 46(8): 1-11.

图/表 18

图1

图2

表1

表2

表3

表4

表5

表6

表7

表8

表9

表10

表11

表12

表13

图3

图4

图5

参考文献 32

[1]	杜永常, 信红梅. 企业“十三五”能源审计及“十四五”节能规划关键问题的探讨[J]. 节能, 2022, 41(6):94-96.
	DU Yongchang, XIN Hongmei.
	Discussion on the key issues of enterprise's "13th Five-year" energy audit and "14th Five-year" energy conservation planning[J]. Energy conservation, 2022, 41(6):94-96.
[2]	莫健文, 纪传伟, 李阳苹, 等. 基于层次分析法的地区节能潜力评价模型研究[J]. 东莞理工学院学报, 2021, 28(5):69-74.
	MO Jianwen, JI Chuanwei, LI Yangping, et al. Research on evaluation model of regional energy saving potential based on analytic hierarchy process[J]. Journal of Dongguan University of Technology, 2021, 28(5):69-74.
[3]	汪涵. 基于DEA模型的江苏省能源效率评价与节能潜力分析[D]. 南京: 南京理工大学, 2023.
	WANG Han. A DEA-based model for energy efficiency evaluation and energy saving potential analysis of Jiangsu province[D]. Nanjing: Nanjing University of Science and Technology, 2023.
[4]	乔富荣. 城市公共机构运行能耗综合评价与节能潜力分析[D]. 广州: 华南理工大学, 2021.
	QIAO Furong. Operation energy consumption comprehensive evaluation and energy saving potential analysis in urban public institutions[D]. Guangzhou: South China University of Technology, 2021.
[5]	宋娇. “双碳”目标下北京市某既有建筑节能减碳潜力分析[J]. 节能, 2023, 42(6):67-69.
	SONG Jiao. Analysis of energy saving and carbon reduction potential of an existing building in Beijing under the goal of "double carbon"[J]. Energy Conservation, 2023, 42(6):67-69.
[6]	杨夏冰. 西安地区高层办公建筑节能减碳设计策略研究[D]. 西安: 西安建筑科技大学, 2023.
	YANG Xiabing. Study on energy conservation and carbon reduction design strategy of high-rise office building in Xi'an[D]. Xi'an: Xi'an University of Architecture and Technology, 2023.
[7]	夏婵, 胡新霞, 王任媛. 上海某医院节能减碳实施路径探析[J]. 绿色建筑, 2023, 15(4):75-78.
	XIA Chan, HU Xinxia, WANG Renyuan. Analysis on the implementation path of energy saving and carbon reduction in a hospital in Shanghai[J]. Green Building, 2023, 15(4):75-78.
[8]	李伯阳. 双碳战略下铝企业碳审计评价指标体系研究[D]. 兰州: 兰州财经大学, 2023.
	LI Boyang. Research on carbon audit evaluation index system of aluminum enterprises under the double-carbon strategy[D]. Lanzhou: Lanzhou University of Finance and Economics, 2023.
[9]	刘贞, 朱开伟, 蒲刚清. 基于LEAP模型的电力需求侧碳减排潜力分析[J]. 电力建设, 2014, 35(6):153-159. doi: 10.3969/j.issn.1000-7229.2014.06.029
	LIU Zhen, ZHU Kaiwei, PU Gangqing. Carbon emission reduction potential of power demand side based on LEAP model[J]. Electric Power Construction, 2014, 35(6):153-159. doi: 10.3969/j.issn.1000-7229.2014.06.029
[10]	李智. 铝型材的成型及机械加工工艺研究[J]. 今日制造与升级, 2023(11):47-49.
	LI Zhi. Study on forming and machining process of aluminum profiles[J]. Manufacture & Upgrading Today, 2023(11):47-49.
[11]	NIU Y Y, SUN Y Z, ZHOU Q, et al. Carbon emission evaluation and potential assessment of energy saving and carbon reduction for iron and steel enterprises[C]// 2023 8th International Conference on Power and Renewable Energy (ICPRE), Shanghai, 2023: 1600-1605.
[12]	TANG T, SUN Y Z, ZHOU Q, et al. Design of energy carbon measurement and carbon emission control platform for high-energy-consuming enterprises[C]// 2023 5th International Conference on Electrical Engineering and Control Technologies (CEECT), Chengdu, 2023: 554-558.
[13]	何向问, 李鹏. 铝加工行业的低碳发展之路[J]. 有色金属加工, 2021, 50(4):1-3.
	HE Xiangwen, LI Peng. Low-carbon development path of aluminum processing industry[J]. Nonferrous Metals Processing, 2021, 50(4):1-3.
[14]	赵淑媛, 辛诚, 陈衡, 等. 基于AHP-熵权法的输变电工程低碳评价体系及方案优选[J]. 广东电力, 2024, 37(1):8-17.
	ZHAO Shuyuan, XIN Cheng, CHEN Heng, et al. Low-carbon evaluation system and solution optimization of transmission and transformation project based on AHP-EWM[J]. Guangdong Electric Power, 2024, 37(1):8-17.
[15]	钟永洁, 纪陵, 李靖霞, 等. 综合能源系统多场景优化运行模式综合评估方法研究[J]. 综合智慧能源, 2023, 45(10):18-24. doi: 10.3969/j.issn.2097-0706.2023.10.003
	ZHONG Yongjie, JI Ling, LI Jingxia, et al. Comprehensive evaluation method for multi-scenario optimization operation modes of the integrated energy system[J]. Integrated Intelligent Energy, 2023, 45(10):18-24. doi: 10.3969/j.issn.2097-0706.2023.10.003
[16]	王伟贤, 孙舟, 潘鸣宇, 等. 基于模糊层次分析法的电动汽车充电桩信息安全风险评估方法[J]. 中国电力, 2021, 54(1):96-103.
	WANG Weixian, SUN Zhou, PAN Mingyu, et al. Information security risk assessment method for electric vehicle charging piles based on fuzzy analytic hierarchy process[J]. Electric Power, 2021, 54(1):96-103.
[17]	虞晓芬, 傅玳. 多指标综合评价方法综述[J]. 统计与决策, 2004(11):119-121.
	YU Xiaofen, FU Dai. Summary of multi-index comprehensive evaluation methods[J]. Statistics and Decision, 2004(11):119-121.
[18]	邓雪, 李家铭, 曾浩健, 等. 层次分析法权重计算方法分析及其应用研究[J]. 数学的实践与认识, 2012, 42(7):93-100.
	DENG Xue, LI Jiaming, ZENG Haojian, et al. Research on computation methods of AHP wight vectorand its applications[J]. Mathematics in Practice and Theory, 2012, 42(7):93-100.
[19]	常建娥, 蒋太立. 层次分析法确定权重的研究[J]. 武汉理工大学学报(信息与管理工程版), 2007(1):153-156.
	CHANG Jian'e, JIANG Taili. Research on the weight of coefficient through analytic hierarchy process[J]. Journal of Wuhan University of Technology(Information & Management Engineering), 2007(1):153-156.
[20]	朱洁, 应费, 季敏捷, 等. 基于SMART原则的超大型城市排水泵站调研评估与分析[J]. 净水技术, 2023, 42(9):142-147,189.
	ZHU Jie, YING Fei, JI Minjie, et al. Investigation, evaluation and analysis of municipal drainage pumping stations in a mega city based on SMART principle[J]. Water Purification Technology, 2023, 42(9):142-147,189.
[21]	胡竞秋, 张轩, 严心然, 等. 基于主客观赋权法的综合能源系统效益评估方法[J]. 广东电力, 2023, 36(1):1-8.
	HU Jingqiu, ZHANG Xuan, YAN Xinran, et al. Benefit evaluation method of comprehensive energy system based on subjective and objective weighting method[J]. Guangdong Electric Power, 2023, 36(1):1-8.
[22]	中华人民共和国工业和信息化部. 变形铝及铝合金单位产品能源消耗限额第3部分:箔材:YS/T 694.3—2017[S]. 北京: 冶金工业出版社, 2017.
[23]	上海市市场监督管理局. 铝箔单位产品能源消耗限额:DB31/T 574—2011[S]. 北京: 中国标准出版社, 2020.
[24]	国家标准化管理委员会. 综合能耗计算通则:GB/T 2589—2020[S]. 北京: 中国标准出版社, 2020.
[25]	佟庆, 吉日格图, 秦旭映. 有色行业控制温室气体排放的前沿探索——其他有色金属冶炼及压延加工业企业温室气体排放核算方法研究[J]. 中国经贸导刊, 2015(31):68-70.
	TONG Qing, JIRI Getu, QIN Xuying. The frontier exploration of controlling greenhouse gas emissions in the non-ferrous industry—Research on greenhouse gas emission accounting methods for other non-ferrous metal smelting and rolling processing enterprises[J]. China Economic & Trade Herald, 2015(31):68-70.
[26]	杨寒雨, 赵晓永, 王磊. 数据归一化方法综述[J]. 计算机工程与应用, 2023, 59(3):13-22. doi: 10.3778/j.issn.1002-8331.2207-0179
	YANG Hanyu, ZHAO Xiaoyong, WANG Lei. Review of data normalization methods[J]. Computer Engineering and Applications, 2023, 59(3):13-22. doi: 10.3778/j.issn.1002-8331.2207-0179
[27]	蔡毅, 邢岩, 胡丹. 敏感性分析综述[J]. 北京师范大学学报(自然科学版), 2008(1):9-16.
	CAI Yi, XING Yan, HU Dan. On sensitivity analysis[J]. Journal of Beijing Normal University(Natural Science), 2008(1):9-16.
[28]	许沛. 绿色建筑节能经济性评价及其敏感性分析研究[D]. 上海: 上海交通大学, 2019.
	XU Pei. The study on economic evaluation and sensitivity analysis of green building energy efficiency[D]. Shanghai: Shanghai Jiaotong University, 2019.
[29]	申融容, 姜丰, 韦泽全, 等. 基于博弈论组合赋权和MARCOS的能源互联网园区项目综合效益评价[J]. 综合智慧能源, 2023, 45(11):70-81. doi: 10.3969/j.issn.2097-0706.2023.11.009
	SHEN Rongrong, JIANG Feng, WEI Zequan, et al. Comprehensive benefit evaluation for energy internet park projects based on combined weight of game[J]. Integrated Intelligent Energy, 2023, 45(11):70-81. doi: 10.3969/j.issn.2097-0706.2023.11.009
[30]	沈坚锋, 许玉德, 李海锋, 等. 轨道几何状态综合评价指标参数权重的敏感性分析[J]. 同济大学学报(自然科学版), 2015, 43(11):1709-1714.
	SHEN Jianfeng, XU Yude, LI Haifeng, et al. Weight sensitivity analysis of parameters of track geometry comprehensive index[J]. Journal of Tongji University(Natural Science), 2015, 43(11): 1709-1714.
[31]	沈岩, 李东东, 林顺富. 碳中和背景下的工业用户综合用能指标体系多维画像方法[J]. 中国电力, 2022, 55(11):91-96.
	SHEN Yan, LI Dongdong, LIN Shunfu. Multi dimensional portrait method of industrial users' comprehensive energy consumption index system under the background of carbon neutrality[J]. Electric Power, 2022, 55(11):91-96.
[32]	王威, 吴晶晶, 葛亚平, 等. 双碳背景下碳排放核算法及策略分析——以铜铝行业为例[J]. 有色金属(冶炼部分), 2022(4):1-11.
	WANG Wei, WU Jingjing, GE Yaping, et al. Carbon emission accounting method and strategy analysis under the background of double carbon: Taking copper and aluminum industry as an example[J]. Nonferrous Metals (Extractive Metallurgy), 2022(4):1-11.

标度量化	含义
1	a指标与b指标一样重要
3	a指标比b指标略微重要
5	a指标比b指标明显重要
7	a指标比b指标重要很多
9	a指标比b指标重要特别多
2,4,6,8	处于2个重要程度之间

一级指标	二级指标	三级指标	指标类型
能效指标	能源消耗量	电力消耗总量	定量计算
		水消耗总量	定量计算
		天然气消耗总量	定量计算
		柴油消耗总量	定量计算
		汽油消耗总量	定量计算
		氮气消耗总量	定量计算
	单位能耗	单位产量能耗	定量计算
	单位能耗	单位工时能耗	定量计算
	能源利用率	设备利用率	定量计算
	能源利用率	热能回收利用率	定量计算
	能源结构	可再生能源占比	定量计算
碳排放指标	碳排放总量	直接碳排放总量	定量计算
	碳排放总量	间接碳排放总量	定量计算
	单位碳排放量	单位产量碳排放量	定量计算
	单位碳排放量	单位工时碳排放量	定量计算
	减排潜力	能效改进潜力	定性打分
	减排技术	节能设备使用程度	定量计算
	减排技术	低碳技术占比	定量计算
环境指标	废水排放率	生产废水排放率	定量计算
	废气排放率	氮氧化物排放率	定量计算
	废气排放率	颗粒物排放率	定量计算
	固体废弃物产生率	废渣产生率	定量计算
	固体废弃物产生率	废品产生率	定量计算
	环境影响评估	噪音影响程度	定性打分
	环境影响评估	气味影响程度	定性打分

项目	折算系数
电力/[kg·(kW·h)^-1]	0.122 9
水/(kg·t^-1)	0.257 1
天然气/(kg·m^-³)	1.100 0
汽油/(kg·kg^-1)	1.428 6
柴油/(kg·kg^-1)	1.457 1
氮气/(kg·t^-1)	0.400 0

能源种类	低位发热量/ (kJ·m^-3)	单位热值含碳量/ ( kg·kJ^-1)	燃料碳氧化率/%
天然气	38 931	15.3×10^-5	0.99
汽油	43 070	18.9×10^-5	0.98
柴油	42 652	20.2×10^-5	0.98

矩阵序号	阶数 n	权重向量	最大特征值	C_I	R_I	C_R
1	3	（0.283,0.643,0.074）^T	3.065	0.032	0.525	0.062
2	4	（0.534,0.309,0.049,0.108）^T	4.194	0.065	0.882	0.073
3	6	（0.435,0.027,0.286,0.153,0.060,0.039）^T	6.443	0.089	1.250	0.071
4	2	（0.833，0.167）^T	2.000	0	0	0
5	2	（0.125，0.875）^T	2.000	0	0	0
6	1	（1.000）^T	1.000	0	0	0
7	4	（0.576,0.291,0.081,0.052）^T	4.202	0.067	0.882	0.076
8	2	（0.250,0.750）^T	2.000	0	0	0
9	2	（0.833,0.167）^T	2.000	0	0	0
10	1	（1.000）^T	1.000	0	0	0
11	2	（0.500,0.500）^T	2.000	0	0	0
12	4	（0.205,0.637,0.113,0.045）^T	4.235	0.078	0.882	0.089
13	1	（1.000）^T	1.000	0	0	0
14	2	（0.875,0.125）^T	2.000	0	0	0
15	2	（0.500,0.500）^T	2.000	0	0	0
16	2	（0.500,0.500）^T	2.000	0	0	0
