基于微波热解技术制备生物炭的研究进展

doi:10.3969/j.issn.2097-0706.2023.05.006

摘要/Abstract

摘要：

随着社会和经济的发展，农林废弃物、生活垃圾、市政污泥及其他有机固体废弃物的无害化处理受到广泛关注。有机固体废弃物中含有大量碳源，通常的处理方法多是填埋、焚烧和作物残余物还土还田，既造成环境污染，又导致碳源资源的浪费。微波热解（MP）是一种比较新颖的生物质热解处理方式，其具有升温速率快、生物质受热均匀、加热效率高等优点。MP可能会以不同于传统管式炉加热的方式影响生物炭的性质，这是因为在不同的加热方式下，传热和传质方式是不同的。主要总结归纳了MP废弃生物质过程中得到的固体生物炭的性质，包括MP方式及特点的描述，对比不同生物质在不同的微波功率和温度影响下，其热解产物的分布和产率变化。着重比较了不同废弃生物质原料经MP后所得生物炭的形貌差异、生物炭表面官能团变化、生物炭孔结构和比表面积的差异、生物炭中各元素的变化及生物炭热稳定性，以及微波生物炭和常规生物炭的差异。

关键词: 固体废弃生物质, 微波热解, 形貌, 表面官能团, 孔结构, 生物炭热稳定性, 碳源资源

Abstract:

With the development of society and economy， the biosafety treatment of agricultural and forestry waste， household waste， municipal sludge and other organic solid waste has attracted wide attention in recent years. Traditional treatments such as landfill ， incineration and crop residue burying are not eco-friendly. Since there are abundant carbon sources in solid wastes， traditional treatments will lead to carbon source loss. Microwave pyrolysis （MP） is an innovative biomass pyrolysis technology with advantages of fast heating rate， uniform heating on biomass and high heating efficiency. MP can affect the properties of biomass in a different way that conventional tube furnace heating does because their heat and mass transfer methods are different. This study summarizes the properties of the solid biochar derived from the MP of disposed biomass and different ways of MP， and compares the product compositions and product yields varying with raw materials， microwave power and temperature. And the research lays focus on the comparison of the morphology， surface functional group， pore structure， specific surface area， element content and thermal stability of biochar obtained from different biomass processed by MP. Finally， the biochar made by MP and conventional method are compared.

Key words: solid waste biomass, microwave pyrolysis, morphology, surface functional group, pore structure, thermal stability of biochar, carbon source

中图分类号:

TK01

蒋雨辰, 李清扬, 胡勋. 基于微波热解技术制备生物炭的研究进展[J]. 综合智慧能源, 2023, 45(5): 46-62.

JIANG Yuchen, LI Qingyang, HU Xun. Research progress of biochar prepared by microwave pyrolysis technology[J]. Integrated Intelligent Energy, 2023, 45(5): 46-62.

图/表 21

图1

图2

表1

图3

图4

图5

图6

图7

图8

图9

图10

图11

表2

表3

图12

图13

图14

图15

图16

图17

图18

参考文献 95

[1]	DEMIRBAS M F, BALAT M, BALAT H. Biowastes-to-biofuels[J]. Energy Conversion and Management, 2011, 52(4): 1815-1828. doi: 10.1016/j.enconman.2010.10.041
[2]	LAVANYA M, MEENAKSHISUNDARAM A, RENGANATHAN S, et al. Hydrothermal liquefaction of freshwater and marine algal biomass: A novel approach to produce distillate fuel fractions through blending and co-processing of biocrude with petrocrude[J]. Bioresource Technology, 2016, 203: 228-235. doi: 10.1016/j.biortech.2015.12.013 pmid: 26735877
[3]	LIN Y, LIAO Y, YU Z, et al. Co-pyrolysis kinetics of sewage sludge and oil shale thermal decomposition using TGA-FTIR analysis[J]. Energy Conversion and Management, 2016, 118: 345-352. doi: 10.1016/j.enconman.2016.04.004
[4]	TRIPATHI M, SAHU J, GANESAN P, et al. Effect of temperature on dielectric properties and penetration depth of oil palm shell(OPS) and OPS char synthesized by microwave pyrolysis of OPS[J]. Fuel, 2015, 153: 257-266. doi: 10.1016/j.fuel.2015.02.118
[5]	LI H, XU J, NYAMBURA S M, et al. Food waste pyrolysis by traditional heating and microwave heating: A review[J]. Fuel, 2022, 324: 124574. doi: 10.1016/j.fuel.2022.124574
[6]	MUBARAK N, SAHU J, ABDULLAH E, et al. Plam oil empty fruit bunch based magnetic biochar composite comparison for synthesis by microwave-assisted and conventional heating[J]. Journal of Analytical and Applied Pyrolysis, 2016, 120: 521-528. doi: 10.1016/j.jaap.2016.06.026
[7]	GUIOTOKU M, RAMBO C R, HOTZA D. Charcoal produced from cellulosic raw materials by microwave-assisted hydrothermal carbonization[J]. Journal of Thermal Analysis and Calorimetry, 2014, 117: 269-275. doi: 10.1007/s10973-014-3676-8
[8]	CHANG A C C, CHANG H F, LIN F J, et al. Biomass gasification for hydrogen production[J]. International Journal of Hydrogen Energy, 2011, 36(21): 14252-14260. doi: 10.1016/j.ijhydene.2011.05.105
[9]	HADIYA V, POPAT K, VYAS S, et al. Biochar production with amelioration of microwave-assisted pyrolysis: Current scenario,drawbacks and perspectives[J]. Bioresource Technology, 2022, 355: 127303. doi: 10.1016/j.biortech.2022.127303
[10]	ZHANG Y, FAN S, LIU T, et al. A review of biochar prepared by microwave-assisted pyrolysis of organic wastes[J]. Sustainable Energy Technologies and Assessments, 2022, 50: 101873. doi: 10.1016/j.seta.2021.101873
[11]	MAŠEK O, BUDARIN V, GRONNOW M, et al. Microwave and slow pyrolysis biochar—Comparison of physical and functional properties[J]. Journal of Analytical and Applied Pyrolysis, 2013, 100: 41-48. doi: 10.1016/j.jaap.2012.11.015
[12]	ROBINSON J, BINNER E, VALLEJO D B, et al. Unravelling the mechanisms of microwave pyrolysis of biomass[J]. Chemical Engineering Journal, 2022, 430: 132975. doi: 10.1016/j.cej.2021.132975
[13]	LAM S S, MAHARI W A W, MA N L, et al. Microwave pyrolysis valorization of used baby diaper[J]. Chemosphere, 2019, 230: 294-302. doi: S0045-6535(19)30950-6 pmid: 31108440
[14]	SUN J, WANG Y C, WANG W L, et al. Application of featured microwave-metal discharge for the fabrication of well-graphitized carbon-encapsulated Fe nanoparticles for enhancing microwave absorption efficiency[J]. Fuel, 2018, 233: 669-676. doi: 10.1016/j.fuel.2018.06.105
[15]	SUN J, WANG Q, WANG W L, et al. Study on the synergism of steam reforming and photocatalysis for the degradation of Toluene as a tar model compound under microwave-metal discharges[J]. Energy, 2018, 155: 815-823. doi: 10.1016/j.energy.2018.05.045
[16]	SUN J, WANG W L, ZHAO C, et al. Study on the coupled effect of wave absorption and metal discharge generation under microwave irradiation[J]. Industrial & Engineering Chemistry Research, 2014, 53(5): 2042-2051. doi: 10.1021/ie403556w
[17]	SONG Z, YAN Y, XIE M, et al. Effect of steel wires on the microwave pyrolysis of tire powders[J]. ACS Sustainable Chemistry & Engineering, 2018, 6(10):13443-13453.
[18]	ZHANG Y Z, BIAN T T, ZHANG Y, et al. Effective and green tire recycling through microwave pyrolysis[J]. Applied Physics & Engineering, 2018, 19(12): 951-960.
[19]	MATHIARASU A, PUGAZHVADIVU M. Studies on dielectric properties and microwave pyrolysis of karanja seed[J]. Biomass Conversion and Biorefinery, 2021: 1-11.
[20]	MORIWAKI S, MACHIDA M, TATSUMOTO H, et al. Dehydrochlorination of poly (vinyl chloride) by microwave irradiation[J]. Applied Thermal Engineering, 2006, 26(7):745-750. doi: 10.1016/j.applthermaleng.2005.09.001
[21]	KOBAYASHI J, HORI M, KOBAYASHI N, et al. Selective dechlorination of polyvinyl chloride by microwave irradiation[J]. Journal of Chemical Engineering of Japan, 2019, 52(7):656-661. doi: 10.1252/jcej.18we219
[22]	HUANG Y F, CHEN W R, CHIUEH P T, et al. Microwave torrefaction of rice straw and pennisetum[J]. Bioresource Technology, 2012, 123: 1-7. doi: 10.1016/j.biortech.2012.08.006 pmid: 22929739
[23]	HUANG Y F, CHIUEH P T, KUAN W H, et al. Microwave pyrolysis of lignocellulosic biomass: Heating performance and reaction kinetics[J]. Energy, 2016, 100: 137-144. doi: 10.1016/j.energy.2016.01.088
[24]	WAN MAHARI W A, ZAINUDDIN N F, WAN NIK W M N, et al. Pyrolysis recovery of waste shipping oil using microwave heating[J]. Energies, 2016, 9(10): 780. doi: 10.3390/en9100780
[25]	LIANG J, XU X, YU Z, et al. Effects of microwave pretreatment on catalytic fast pyrolysis of pine sawdust[J]. Bioresource Technology, 2019, 293: 122080. doi: 10.1016/j.biortech.2019.122080
[26]	PIANROJ Y, JUMRAT S, WERAPUN W, et al. Scaled-up reactor for microwave induced pyrolysis of oil palm shell[J]. Chemical Engineering and Processing:Process Intensification, 2016, 106: 42-49. doi: 10.1016/j.cep.2016.05.003
[27]	LI X, PENG B, LIU Q, et al. Microwave pyrolysis coupled with conventional pre-pyrolysis of the stalk for syngas and biochar[J]. Bioresource Technology, 2022, 348: 126745. doi: 10.1016/j.biortech.2022.126745
[28]	GANESAPILLAI M, MANARA P, ZABANIOTOU A. Effect of microwave pretreatment on pyrolysis of crude glycerol-olive kernel alternative fuels[J]. Energy Conversion and Management, 2016, 110: 287-295. doi: 10.1016/j.enconman.2015.12.045
[29]	LAM S S, LIEW R K, WONG Y M, et al. Activated carbon for catalyst support from microwave pyrolysis of orange peel[J]. Waste Biomass Valor, 2017, 8: 2109-2119. doi: 10.1007/s12649-016-9804-x
[30]	HALIM S A, SWITHENBANK J. Characterisation of malaysian wood pellets and rubberwood using slow pyrolysis and microwave technology[J]. Journal of Analytical and Applied Pyrolysis, 2016, 122: 64-75. doi: 10.1016/j.jaap.2016.10.021
[31]	HUANG Y F, KUAN W H, CHANG C Y. Effects of particle size, pretreatment, and catalysis on microwave pyrolysis of corn stover[J]. Energy, 2018, 143: 696-703. doi: 10.1016/j.energy.2017.11.022
[32]	PRASHANTH P F, KUMAR M M, VINU R. Analytical and microwave pyrolysis of empty oil palm fruit bunch: Kinetics and product characterization[J]. Bioresource Technology, 2020, 310: 123394. doi: 10.1016/j.biortech.2020.123394
[33]	DONG Q, LI X, WANG Z, et al. Effect of iron(III) ion on moso bamboo pyrolysis under microwave irradiation[J]. Bioresource Technology, 2017, 243: 755-759. doi: S0960-8524(17)31095-7 pmid: 28711804
[34]	CHEN C, QI Q, ZHAO J, et al. Study on microwave pyrolysis and production characteristics of Chlorella vulgaris using different compound additives[J]. Bioresource Technology, 2021, 341: 125857. doi: 10.1016/j.biortech.2021.125857
[35]	HUANG Y F, KUAN W H, CHANG C C, et al. Catalytic and atmospheric effects on microwave pyrolysis of corn stover[J]. Bioresource Technology, 2013, 131: 274-280. doi: 10.1016/j.biortech.2012.12.177
[36]	ZHAO X, WANG W, LIU H, et al. Microwave pyrolysis of wheat straw:Product distribution and generation mechanism[J]. Bioresource Technology, 2014, 158: 278-285. doi: 10.1016/j.biortech.2014.01.094
[37]	ZHOU R, LEI H, JULSON J. The effects of pyrolytic conditions on microwave pyrolysis of prairie cordgrass and kinetics[J]. Journal of Analytical and Applied Pyrolysis, 2013, 101: 172-176. doi: 10.1016/j.jaap.2013.01.013
[38]	LIU H, MA X, LI L, et al. The catalytic pyrolysis of food waste by microwave heating[J]. Bioresource Technology, 2014, 166: 45-50. doi: 10.1016/j.biortech.2014.05.020 pmid: 24905041
[39]	Al SHRA'AH A, HELLEUR R. Microwave pyrolysis of cellu-lose at low temperature[J]. Journal of Analytical and Applied Pyrolysis, 2014, 105: 91-99. doi: 10.1016/j.jaap.2013.10.007
[40]	ISMAIL K, ISHAK M A M, AB GHANI Z, et al. Microwave-assisted pyrolysis of palm kernel shell: Optimization using response surface methodology (RSM)[J]. Renewable Energy, 2013, 55: 357-365. doi: 10.1016/j.renene.2012.12.042
[41]	MOKHLISSE A, CHANÂA M B, OUTZOURHIT A. Pyrolysis of the Moroccan (Tarfaya) oil shales under microwave irradiation[J]. Fuel, 2000, 79: 733-742. doi: 10.1016/S0016-2361(99)00209-4
[42]	CHEN M, WANG J, ZHANG M, et al. Catalytic effects of eight inorganic additives on pyrolysis of pine wood sawdust by microwave heating[J]. Journal of Analytical and Applied Pyrolysis, 2008, 82(1): 145-150. doi: 10.1016/j.jaap.2008.03.001
[43]	UNDRI A, ROSI L, FREDIANI M, et al. Microwave assisted pyrolysis of corn derived plastic bags[J]. Journal of Analytical and Applied Pyrolysis, 2014, 108: 86-97. doi: 10.1016/j.jaap.2014.05.013
[44]	YUAN T, TAHMASEBI A, YU J. Comparative study on pyrolysis of lignocellulosic and algal biomass using a thermogravimetric and a fixed-bed reactor[J]. Bioresource Technology, 2015, 175: 333-341. doi: 10.1016/j.biortech.2014.10.108 pmid: 25459840
[45]	ABUBAKAR Z, ANI F N. Microwave-assisted pyrolysis of oil palm shell biomass[J]. Jurnal Mekanikal, 2013, 36: 19-30.
[46]	ZHAO X, SONG Z, LIU H, et al. Microwave pyrolysis of corn stalk bale: A promising method for direct utilization of large-sized biomass and syngas production[J]. Journal of Analytical and Applied Pyrolysis, 2010, 89: 87-94. doi: 10.1016/j.jaap.2010.06.001
[47]	BU Q, LEI H, REN S, et al. Production of phenols and biofuels by catalytic microwave pyrolysis of lignocellulosic biomass[J]. Bioresource Technology, 2012, 108: 274-279. doi: 10.1016/j.biortech.2011.12.125 pmid: 22261662
[48]	HUANG Y, CHIUEH P, KUAN W, et al. Effects of lignocellulosic composition and microwave power level on the gaseous product of microwave pyrolysis[J]. Energy, 2015, 89: 974-981. doi: 10.1016/j.energy.2015.06.035
[49]	MOTASEMI F, AFZAL M T. A review on the microwave-assisted pyrolysis technique[J]. Renewable and Sustainable Energy Reviews, 2013, 28: 317-330. doi: 10.1016/j.rser.2013.08.008
[50]	JAMARI S S, HOWSE J R. The effect of the hydrothermal carbonization process on palm oil empty fruit bunch[J]. Biomass and Bioenergy, 2012, 47: 82-90. doi: 10.1016/j.biombioe.2012.09.061
[51]	LIN B, CHEN W. Sugarcane bagasse pyrolysis in a carbon dioxide atmosphere with conventional and microwave-assisted heating[J]. Frontier in Energy Research, 2015, 3: 4.
[52]	SONG Z, YANG Y, SUN J, et al. Effect of power level on the microwave pyrolysis of tire powder[J]. Energy, 2017, 127: 571-580. doi: 10.1016/j.energy.2017.03.150
[53]	YANG D, PENG X, PENG Q, et al. Probing the interfacial forces and surface interaction mechanisms in petroleum production processes[J]. Engineering, 2022.DOI:10.1016/j.eng.2022.06.012. doi: 10.1016/j.eng.2022.06.012
[54]	ZHANG J, TIAN Y, YIN L, et al. Insight into the effects of biochar as adsorbent and microwave receptor from one-step microwave pyrolysis of sewage sludge[J]. Environmental Science and Pollution Research, 2018, 25: 18424-18433. doi: 10.1007/s11356-018-2028-9
[55]	WANG X, CHEN H, LUO K, et al. The influence of microwave drying on biomass pyrolysis[J]. Energy & Fuels, 2008, 22(1): 67-74. doi: 10.1021/ef700300m
[56]	GAO H, BAI J, WEI Y, et al. Effects of drying pretreatment on microwave pyrolysis characteristics of tobacco stems[J]. Biomass Conversion and Biorefinery, 2022: 1-11.
[57]	ZHOU J, WU L, LIANG K, et al. The synergistic mechanism on microwave and MoS₂ in coal pyrolysis[J]. Journal of Analytical and Applied Pyrolysis, 2018, 134: 580-589. doi: 10.1016/j.jaap.2018.08.007
[58]	ZI W, CHEN Y, PAN Y, et al. Pyrolysis, morphology and microwave absorption properties of tobacco stem materials[J]. Science of the Total Environment, 2019, 683: 341-350. doi: 10.1016/j.scitotenv.2019.04.053
[59]	ZHOU G, HUANG Q, YU B, et al. Effect of industrial microwave irradiation on the physicochemical properties and pyrolysis characteristics of lignite[J]. Chinese Journal of Chemical Engineering, 2017, 26(5):1171-1178. doi: 10.1016/j.cjche.2017.11.002
[60]	SALEMA A A, AFZAL M T, BENNAMOUN L. Pyrolysis of corn stalk biomass briquettes in a scaled-up microwave technology[J]. Bioresource Technology, 2017, 233: 353-362. doi: S0960-8524(17)30242-0 pmid: 28285228
[61]	HAELDERMANS T, CLAESEN J, MAGGEN J, et al. Microwave assisted and conventional pyrolysis of MDF—Characterization of the produced biochars[J]. Journal of Analytical and Applied Pyrolysis, 2019, 138: 218-230. doi: 10.1016/j.jaap.2018.12.027
[62]	DURÁN-JIMÉNEZ G, HERNÁNDEZ-MONTOYA V, MONTES-MORÁN M A, et al. Microwave pyrolysis of pecan nut shell and thermogravimetric, textural and spectroscopic characterization of carbonaceous products[J]. Journal of Analytical and Applied Pyrolysis, 2018, 135: 160-168. doi: 10.1016/j.jaap.2018.09.007
[63]	FAN J, SHUTTLEWORTH P S, GRONNOW M, et al. Influence of density on microwave pyrolysis of cellulose[J]. ACS Sustainable Chemistry & Engineering, 2018, 6(3): 2916-2920.
[64]	GE L C, ZHANG Y W, WANG Z H, et al. Effects of microwave irradiation treatment on physicochemical characteristics of Chinese low-rank coals[J]. Energy Conversion and Management, 2013, 71: 84-91. doi: 10.1016/j.enconman.2013.03.021
[65]	JING X, DONG J, HUANG H, et al. Interaction between feedstocks, absorbers and catalysts in the microwave pyrolysis process of waste plastics[J]. Journal of Cleaner Production, 2021, 291: 125857. doi: 10.1016/j.jclepro.2021.125857
[66]	LAM S S, SU M H, NAM W L, et al. Microwave pyrolysis with steam activation in producing activated carbon for removal of herbicides in agricultural surface water[J]. Industrial & Engineering Chemistry Research, 2018, 58(2): 695-703. doi: 10.1021/acs.iecr.8b03319
[67]	KOSTAS E T, DURÁN-JIMÉNEZ G, SHEPHERD B J, et al. Microwave pyrolysis of olive pomace for bio-oil and bio-char production[J]. Chemical Engineering Journal, 2020, 387: 123404. doi: 10.1016/j.cej.2019.123404
[68]	MONG G R, CHONG C T, NG J H, et al. Microwave pyrolysis for valorisation of horse manure biowaste[J]. Energy Conversion and Management, 2020, 220: 113074. doi: 10.1016/j.enconman.2020.113074
[69]	SANGJAN A, NGAMSIRI P, KLOMKLIANG N, et al. Effect of microwave-assisted wet torrefaction on liquefaction of biomass from palm oil and sugarcane wastes to bio-oil and carbon nanodots/nanoflakes by hydrothermolysis and solvothermolysis[J]. Renewable Energy, 2020, 154: 1204-1217. doi: 10.1016/j.renene.2020.03.070
[70]	谢为, 卜权. 微波热解醋糟制备生物炭及其吸附性能研究[J]. 江苏农业科学, 2020, 48(6):194-199.
	XIE Wei, BU Quan. Preparation of biochar by microwave pyrolysis of vinegar residue and research of its absorbability[J]. Jiangsu Agricultural Sciences, 2020, 48(6): 194-199.
[71]	LESTINSKY P, GRYCOVA B, PRYSZCZ A, et al. Hydrogen production from microwave catalytic pyrolysis of spruce sawdust[J]. Journal of Analytical and Applied Pyrolysis, 2017, 124: 175-179. doi: 10.1016/j.jaap.2017.02.008
[72]	DONG Q, REN S, ZHANG S, et al. Role of calcium ion in moso bamboo pyrolysis under microwave irradiation[J]. Fuel Processing Technology, 2021, 211: 106598. doi: 10.1016/j.fuproc.2020.106598
[73]	LAM S S, LIEW R K, CHENG C K, et al. Catalytic microwave pyrolysis of waste engine oil using metallic pyrolysis char[J]. Applied Catalysis B: Environmental, 2015, 176: 601-617.
[74]	WANG N, TAHMASEBI A, YU J, et al. A comparative study of microwave-induced pyrolysis of lignocellulosic and algal biomass[J]. Bioresource Technology, 2015, 190: 89-96. doi: 10.1016/j.biortech.2015.04.038 pmid: 25935388
[75]	WANG X H, CHEN H P, DING X J, et al. Properties of gas and char from microwave pyrolysis of pine sawdust[J]. BioResources, 2009, 4(3):946-959.
[76]	HUANG Y F, CHIUEH P T, SHIH C H, et al. Microwave pyrolysis of rice straw to produce biochar as an adsorbent for CO₂ capture[J]. Energy, 2015, 84: 75-82. doi: 10.1016/j.energy.2015.02.026
[77]	LIU Y, CHEN T, GAO B, et al. Comparison between hydrogen-rich biogas production from conventional pyrolysis and microwave pyrolysis of sewage sludge: Is microwave pyrolysis always better in the whole temperature range?[J]. International Journal of Hydrogen Energy, 2021, 46(45): 23322-23333. doi: 10.1016/j.ijhydene.2020.05.165
[78]	肖春龙. 污泥气化合成气生成特性及其BP神经网络预测模型研究[D]. 杭州: 浙江工业大学, 2015.
	XIAO Chunlong. Study on the sludge gasification syngas generation characteristics and BP neural network prediction model[D]. Hangzhou: Zhejiang University of Technology, 2015.
[79]	LIU S Y, ZHANG Y N, FAN L L, et al. Bio-oil production from sequential two step catalytic fast microwave[J]. Fuel, 2017, 196: 261-268. doi: 10.1016/j.fuel.2017.01.116
[80]	FENG Y, LI Y, WANG J C, et al. Insights to the microwave effect in the preparation of sorbent for H₂S removal:Desulfurization kinetics and characterization[J]. Fuel, 2017, 203: 233-243. doi: 10.1016/j.fuel.2017.04.095
[81]	BARTOLI M, ROSI L, GIOVANNELLI A, et al. Pyrolysis of α-cellulose using a multimode microwave oven[J]. Journal of Analytical and Applied Pyrolysis, 2016, 120: 284-296. doi: 10.1016/j.jaap.2016.05.016
[82]	BARTOLI M, ROSI L, GIOVANNELLI A, et al. Microwave assisted pyrolysis of crop residues from Vitis vinifera[J]. Journal of Analytical and Applied Pyrolysis, 2018, 130: 305-313. doi: 10.1016/j.jaap.2017.12.018
[83]	HE L, MA Y, YUE C, et al. Transformation mechanisms of organic S/N/O compounds during microwave pyrolysis of oil shale:A comparative research with conventional pyrolysis[J]. Fuel Processing Technology, 2021, 212: 106605. doi: 10.1016/j.fuproc.2020.106605
[84]	DOUCET J, LAVIOLETTE J P, FARAG S, et al. Distributed microwave pyrolysis of domestic waste[J]. Waste and Biomass Valorization, 2014, 5: 1-10. doi: 10.1007/s12649-013-9216-0
[85]	BENEROSO D, ARENILLAS A, MONTES-MORÁN M A, et al. Ecotoxicity tests on solid residues from microwave induced pyrolysis of different organic residues:An addendum[J]. Journal of Analytical and Applied Pyrolysis, 2016, 121: 329-332. doi: 10.1016/j.jaap.2016.08.013
[86]	ELAIGWU S E, ROCHER V, KYRIAKOU G, et al. Removal of Pb²⁺ and Cd²⁺ from aqueous solution using chars from pyrolysis and microwave-assisted hydrothermal carbonization of Prosopis africana shell[J]. Journal of Industrial and Engineering Chemistry, 2014, 20(5): 3467-3473. doi: 10.1016/j.jiec.2013.12.036
[87]	PARSHETTI G K, HOEKMAN S K, BALASUBRAMANIAN R. Chemical,structural and combustion characteristics of carbonaceous products obtained by hydrothermal carbonization of palm empty fruit bunches[J]. Bioresource Technology, 2013, 135:683-689. doi: 10.1016/j.biortech.2012.09.042
[88]	SHANG H, LU R, SHANG L, et al. Effect of additives on the microwave-assisted pyrolysis of sawdust[J]. Fuel Processing Technology, 2015, 131: 167-174. doi: 10.1016/j.fuproc.2014.11.025
[89]	ZHOU N, DAI L, LV Y, et al. Catalytic pyrolysis of plastic wastes in a continuous microwave assisted pyrolysis system for fuel production[J]. Chemical Engineering Journal, 2021, 418: 129412. doi: 10.1016/j.cej.2021.129412
[90]	LIANG J, YU Z, CHEN L, et al. Microwave pretreatment power and duration time effects on the catalytic pyrolysis behaviors and kinetics of water hyacinth[J]. Bioresource Technology, 2019, 286: 121369. doi: 10.1016/j.biortech.2019.121369
[91]	WU C, BUDARIN V L, WANG M, et al. CO₂ gasification of bio-char derived from conventional and microwave pyrolysis[J]. Applied Energy, 2015, 157: 533-539. doi: 10.1016/j.apenergy.2015.04.075
[92]	GRONNOW M J, BUDARIN V L, MAŠEK O, et al. Torrefaction/biochar production by microwave and conventional slow pyrolysis-comparison of energy properties[J]. Gcb Bioenergy, 2013, 5(2): 144-152. doi: 10.1111/gcbb.12021
[93]	安杨, 邱晶晶, 李丽丽, 等. 催化重整微藻微波热解挥发分制芳烃和富氢合成气[J]. 可再生能源, 2022, 40(10): 1288-1295.
	AN Yang, QIU Jingjing, LI Lili, et al. Catalytic reforming microalgae and microwave pyrolysis volatile for the production of aromatic hydrocarbons and hydrogen-rich syngas[J]. Renewable Energy Resources, 2022, 40(10): 1288-1295.
[94]	张彤, 王晴东, 王光华, 等. 改性分子筛催化褐煤微波热解挥发分提质研究[J]. 煤化工, 2022, 50(3): 98-103.
	ZHANG Tong, WANG Qingdong, WANG Guanghua, et al. Research on quality improvement of lignite volatiles during microwave pyrolysis catalyzed by modified molecular sieve[J]. Coal Chemical Industry, 2022, 50(3): 98-103.
[95]	蒋华义, 胡娟, 齐红媛, 等. 磁性纳米粒子类型和质量浓度对微波热解含油污泥的影响[J]. 化工进展, 2022, 41(7):3908-3914. doi: 10.16085/j.issn.1000-6613.2021-1914
	JIANG Huayi, HU Juan, QI Hongyuan, et al. Effect of magnetic nanoparticles type and mass concentration on oily sludge during microwave pyrolysis[J]. Chemical Industry and Engineering Progress, 2022, 41(7): 3908-3914. doi: 10.16085/j.issn.1000-6613.2021-1914

原料	微波功率/W	温度/℃	生物炭/%	生物油/%	气体/%
straw^[11]	1 200	200	33.70	28.7	37.6
willow^[11]	1 200	170	27.30	42.2	30.5
malaysian wood^[30]	1 000	800	21.80	26.2	52.0
rubber wood^[30]	1 000	800	21.40	19.1	59.5
corn stover^[31]	500	522	15.00	12.0	73.0
oil palm shell^[32]	600	900	26.00	39.0	35.0
moso bamboo^[33]	800	650	18.00	35.0	47.0
chlorella^[34]	—	900	28.40	14.7	56.9
corn stover^[35]	500	—	19.00	18.0	63.0
wheat straw^[36]	800	—	27.40	26.1	46.5
cordgrass^[37]	700	650	26.70	28.0	45.3
food waste^[38]	300	—	81.60	11.9	6.5
cellulose^[39]	300	200~280	35.00~70.00	45.0~52.0	5.0~35.0
palm kernel shell^[40]	100~1 000	—	40.00	—	—
tarfaya oil shale^[41]	300~600	—	—	5.6~4.2	9.3~14.2
pine wood sawdust^[42]	1 000	470	17.30~40.30	16.0~26.0	36.0~60.0
core derived plastic bags^[43]	1 200~3 000	345~535	11.10~32.70	22.3~47.6	28.7~46.2
waste multilayer packaging beverage^[44]	3 000	345~600	28.70~43.30	31.1~60.6	9.0~42.5
oil palm shell^[45]	450	500~650	26.00~42.00	20.0~28.0	37.0~46.0
cornstalk bale^[46]	334~668	—	—	—	50.0
douglas fir^[47]	700	315~485	—	12.5~48.1	11.8~57.5
rice straw^[48]	300~500	—	26.00~31.00	50.0	18.0~26.0
sewage sludge and rice straw^[49]	100~400	—	38.71~77.75	—	—
polystyrenee^[50]	2 000	—	19.00	71.0	9.0
sugarcane bagasse^[51]	—	550	61.90~83.20	14.4~22.0	2.4~16.1

原料	微波功率/W	温度/℃	比表面积/(m²·g^-1)	孔容积/(cm³·g^-1)
straw^[11]	1 200	200	1.1	0.37
willow^[11]	1 200	170	3.9	2.10
malaysian wood^[30]	1 000	800	350.9	0.19
rubber wood^[30]	1 000	800	238.6	0.16
sludge^[54]	1 200	—	459.0	0.23
spruce sawdust^[71]	400	—	341.0	0.19
tobacco straw^[56]	—	550	9.9	0.03
cotton stalk^[27]	600	700	94.5	0.21
flavedo^[29]	700	—	1 015.0	0.50
wheat straw^[36]	600	—	32.0	0.03
moso bamboo^[72]	800	—	10.5	0.02
pecan shell^[62]	400	—	306.0	0.18
waste oil^[73]	—	—	124.0	0.13
washed rice husk^[74]	—	—	267.8	0.20
washed and pretreated rice husk^[74]	—	—	157.8	0.13
rice straw^[49]	—	—	93.0~122.2	0.06~0.08
wheat straw^[75]	—	—	7.0~128.7	0.01~0.09
rice husk^[74]	—	—	217.0	0.13
pretreated rice husk^[74]	—	—	187.7	0.13
sewage sludge^[49]	—	—	24.8~51.5	0.02~0.03
rice straw^[76]	—	—	31.6~122.2	0.03~0.08

原料	微波功率/W	温度/℃	w(C)/%	w(H)/%	w(N)/%	w(O)/%
oil palm shell^[32]	600	900	72.2	1.20	0.60	18.7
oil shale^[83]	600	520	83.8	8.90	1.20	2.6
malaysian wood^[30]	1 000	800	89.3	1.20	0.34	9.2
rubber wood^[30]	1 000	800	88.9	0.38	0.49	9.8
cornstalk^[60]	900	—	74.3	1.90	0.35	23.5
polystyrene^[84]	2 000	—	96.2	0.52	0.13	—
paper^[84]	2 000	—	92.2	2.00	0.21	—
cotton stalk^[27]	600	700	43.5	6.40	0.62	42.9
meat^[84]	2 000	—	91.7	1.60	2.00	—
straw^[85]	—	800	64.7	0.50	0.80	1.5
municipalsolid waste^[85]	—	800	21.1	0.20	0.80	0.9
pecan shell^[62]	400	—	82.0	1.30	0.10	16.7
waste oil^[73]	—	—	86.3	4.00	0.20	9.0
rice husk^[74]	—	—	44.7	1.80	0.73	7.7
pretreated rice husk^[74]	—	—	48.9	1.90	0.90	6.1
packaging beverage^[44]	—	—	66.0	1.00	0.50	—
waste tires^[76]	—	—	82.3~92.0	0.32~3.20	0.00~0.78	—
pine sawdust^[75]	—	—	89.4~93.1	0.98~2.50	0.14~0.24	5.5~7.7
prosopis africana shell^[86]	—	—	70.8	4.70	1.60	22.9
wood^[87]	—	—	59.3~63.9	5.80~7.20	2.30~2.40	28.0~32.0
washed rice husk^[74]	—	—	44.4	1.80	0.80	8.9
washed and pretreated rice husk^[74]	—	—	46.0	2.00	0.80	9.5
sewage sludge and rice straw^[49]	—	—	—	—	—	—
wheat straw^[75]	—	—	46.9~64.6	0.80~2.10	0.53~1.32	26.4~45.9
waste tire^[88]	—	—	85.0~87.7	8.50~11.80	0.02~0.76	—
