基于密度修正的风电功率曲线线性拟合模型

doi:10.3969/j.issn.2097-0706.2025.03.008

综合智慧能源 ›› 2025, Vol. 47 ›› Issue (3): 84-91.doi: 10.3969/j.issn.2097-0706.2025.03.008

基于密度修正的风电功率曲线线性拟合模型

朱东杰¹(), 吕昆烨²^,^*(), 宋长虹², 江美慧³^,⁴, 李枝玖²

1.中国华电集团贵港发电有限公司，广西贵港 537100
2.广西电力职业技术学院电力工程学院，南宁 530001
3.广西大学电气工程学院，南宁 530004
4.内蒙古工业大学新能源学院，内蒙古鄂尔多斯 017010

收稿日期:2024-12-12 修回日期:2025-02-04 接受日期:2025-03-25 出版日期:2025-03-25
通讯作者: *吕昆烨（1995），男，助教，硕士，从事风电建模、分布式发电与微电网方面的研究，kunyelv@yeah.net。
作者简介:朱东杰（1980），男，工程师，硕士，从事新能源发电方面的研究，zhudongjie80@yeah.net。
基金资助:
国家自然科学基金项目(52107083);广西科技重大专项(AA22068071)

Linear fitting model for wind power curves based on density correction

ZHU Dongjie¹(), LYU Kunye²^,^*(), SONG Changhong², JIANG Meihui³^,⁴, LI Zhijiu²

1. China Huadian Corporation Guigang Power Company Limited， Guigang 537100， China
2. School of Electrical Engineering， Guangxi Electrical Polytechnic Institute， Nanning 530001， China
3. School of Electrical Engineering， Guangxi University， Nanning 530004， China
4. School of Renewable Energy， Inner Mongolia University of Technology， Ordos 017010， China

Received:2024-12-12 Revised:2025-02-04 Accepted:2025-03-25 Published:2025-03-25
Supported by:
National Natural Science Foundation of China(52107083);Guangxi Science and Technology Major Project(AA22068071)

摘要/Abstract

摘要：

针对传统风电功率曲线难以计及气象因素的影响而导致模型精度变低的问题，提出了一种考虑密度修正的风电功率曲线线性拟合模型LI-DASW。建立了基于气温、气压、湿度等气象因素的空气密度计算模型以及密度修正风速策略，既能反映气象因素变化对风电功率曲线的影响，又能保持模型的单输入单输出特性。以一阶矩替代原数据集合建模，减少冗余计算，提升建模效率；然后以一阶矩为插值点构建线性插值模型，有效规避了高阶多项式拟合带来的Runge现象，增强模型适应性。两个风电场的算例分析结果表明，LI-DASW模型拟合性能明显优于传统方法：相较于Bin法，模型的均方根误差（RMSE）分别降低了14.42%和10.16%，平均绝对误差（MAE）降幅达15.63%和9.48%；与多项式方法相比，RMSE降幅提升至20.33%和7.66%，MAE改进幅度分别为18.15%和8.06%；相较于线性插值方法，RMSE和MAE降低了6.19%∼7.37%；同时，建模效率较多项式模型提高了84.81%以上。

关键词: 风电, 功率曲线, 线性拟合模型, 气象因素, 密度修正风速策略, 一阶矩, 线性插值

Abstract:

To address the issue that traditional wind power curve models fail to fully consider the effect of meteorological factors， resulting in reduced model accuracy， a new linear fitting model for wind power curves named LI-DASW is proposed with the inclusion of density correction. A calculation model for air density was developed based on meteorological factors such as temperature， pressure， and humidity， as well as a density-corrected wind speed strategy. It reflected the effect of meteorological changes on the wind power curve while maintaining the model's single-input and single-output characteristics. The original dataset was replaced with the first moment to reduce redundant calculations and improve modeling efficiency. A linear interpolation model was constructed using the first moment as interpolation points， effectively avoiding the Runge's phenomenon caused by higher-order polynomial fitting and enhancing the model's adaptability. The case study analysis results of two wind farms demonstrated that the LI-DASW model significantly outperformed traditional methods. Compared to the Bin method， the model's root mean square error（RMSE） reduced by 14.42% and 10.16%， and the mean absolute error（MAE） decreased by 15.63% and 9.48%， respectively. Compared to the polynomial method， the RMSE decreased by 20.33% and 7.66%， and the MAE improved by 18.15% and 8.06%. Compared to the linear interpolation method， the reductions in RMSE and MAE remained stable between 6.19% to 7.37%. Additionally， the modeling efficiency improved by over 84.81% compared to the polynomial model.

Key words: wind power, power curve, linear fitting model, meteorological factors, density-corrected wind speed strategy, first moment, linear interpolation

中图分类号:

TK81

朱东杰, 吕昆烨, 宋长虹, 江美慧, 李枝玖. 基于密度修正的风电功率曲线线性拟合模型[J]. 综合智慧能源, 2025, 47(3): 84-91.

ZHU Dongjie, LYU Kunye, SONG Changhong, JIANG Meihui, LI Zhijiu. Linear fitting model for wind power curves based on density correction[J]. Integrated Intelligent Energy, 2025, 47(3): 84-91.

图/表 10

表1

表2

表3

图1

表4

表5

图2

图3

图4

图5

参考文献 27

[1]	TUNCAR A E, SAĞLAM Ş, ORAL B. A review of short-term wind power generation forecasting methods in recent technological trends[J]. Energy Reports, 2024,12:197-209.
[2]	LI Y T, WANG P, WU Z Y, et al. Collaborative monitoring of wind turbine performance based on probabilistic power curve comparison[J]. Renewable Energy, 2024, 231:120919.
[3]	RODRÍGUEZ-LÓPEZ M Á, CERDÁ E, RIO P D. Modeling wind-turbine power curves: Effects of environmental temperature on wind energy generation[J]. Energies, 2020, 13(18):4941.
[4]	张真真. 风电机组功率曲线不达标原因分析及优化措施[J]. 分布式能源, 2021, 6(5): 71-76.
	ZHANG Zhenzhen. Cause analysis and optimization measures for wind turbine substandard power curve[J]. Distributed Energy, 2021, 6(5): 71-76.
[5]	黄哲, 高政南, 杭晨辉, 等. 基于历史运行数据的风电场理论输出功率计算方法分析[J]. 内蒙古电力技术, 2016, 34(6): 1-6.
	HUANG Zhe, GAO Zhengnan, HANG Chenhui, et al. Calculation method analysis of theoretical output power of wind farm based on historical running data[J]. Inner Mongolia Electric Power, 2016, 34(6): 1-6.
[6]	LIN Q C, CAI H L, LIU H W, et al. A novel ultra-short-term wind power prediction model jointly driven by multiple algorithm optimization and adaptive selection[J]. Energy, 2024, 288:129724.
[7]	殷林飞, 蒙雨洁. 基于DenseNet卷积神经网络的短期风电预测方法[J]. 综合智慧能源, 2024, 46(7): 12-20. doi: 10.3969/j.issn.2097-0706.2024.07.002
	YIN Linfei, MENG Yujie. Short-term wind power forecasting based on DenseNet convolutional neural networks[J]. Integrated Intelligent Energy, 2024, 46(7): 12-20. doi: 10.3969/j.issn.2097-0706.2024.07.002
[8]	殷林飞, 仝博文, 李雯吉. 基于多尺度卷积-残差网络的短期风电预测[J/OL]. 综合智慧能源,1-10(2024-09-05)[2024-12-01]. http://kns.cnki.net/kcms/detail/41.1461.TK.20240904.1013.002.html.
	YIN Linfei, TONG Bowen, LI Wenji. Multiscale convolution-residual network for short-term wind power forecasting[J/OL]. Integrated Intelligent Energy,1-10(2024-09-05)[2024-12-01]. http://kns.cnki.net/kcms/detail/41.1461.TK.20240904.1013.002.html.
[9]	LYDIA M, KUMAR S S, SELVAKUMAR A I, et al. A comprehensive review on wind turbine power curve modeling techniques[J]. Renewable and Sustainable Energy Reviews, 2014, 30:452-460.
[10]	沈小军, 付雪姣. 基于改进光滑样条的风电机组功率曲线建模方法[J]. 高电压技术, 2020, 46(7): 2418-2424.
	SHEN Xiaojun, FU Xuejiao. Modeling of wind turbine power curve based on improved smoothing spline[J]. High Voltage Engineering, 2020, 46(7): 2418-2424.
[11]	WANG Y, HU Q H, SRINIVASAN D, et al. Wind power curve modeling and wind power forecasting with inconsistent data[J]. IEEE Transactions on Sustainable Energy, 2019, 10(1):16-25.
[12]	ÜSTÜNTAŞ T, ŞAHIN A D. Wind turbine power curve estimation based on cluster center fuzzy logic modeling[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2008, 96(5):611-620.
[13]	LÁZARO R, YÜRÜŞEN N Y, MELERO J J. Wind turbine power curve modelling using gaussian mixture copula, ANN regressive and BANN[J]. Journal of physics. Conference Series, 2022, 2265(3):32083.
[14]	KOUISSI M, EN-NAIMI E M, ZOUHAIR A. Hybrid approach for wind turbines power curve modeling founded on multi-agent system and two machine learning algorithms, k-means method and the k-nearest neighbors, in the retrieve phase of the dynamic case based reasoning[J]. International Journal of online and Biomedical Engineering, 2022, 18(6):110-122.
[15]	CAPELLETTI M, RAIMONDO D M, DE NICOLAO G. Wind power curve modeling: A probabilistic Beta regression approach[J]. Renewable Energy, 2024, 223:119970.
[16]	VIRGOLINO G C M, MATTOS C L C, MAGALHÃES J A F, et al. Gaussian processes with logistic mean function for modeling wind turbine power curves[J]. Renewable Energy, 2020, 162:458-465.
[17]	WANG Y, DUAN X, SONG D, et al. Wind power curve modeling with large-scale generalized kernel-based regression model[J]. IEEE Transactions on Sustainable Energy, 2023, 14(4):2121-2132.
[18]	YANG L X, WANG L, ZHANG Z J. Generative wind power curve modeling via machine vision: A deep convolutional network method with data-synthesis-informed-training[J]. IEEE Transactions on Power Systems, 2023, 38(2):1111-1124.
[19]	ZHA W T, JIN Y, SUN Y L, et al. A wind speed vector-wind power curve modeling method based on data denoising algorithm and the improved Transformer[J]. Electric Power Systems Research, 2023, 214:108838.
[20]	PRAANJAL N, AHMED E A. Yaw-adjusted wind power curve modeling: A local regression approach[J]. Renewable Energy, 2023, 202:1368-1376.
[21]	ZHENG Z, YANG L X, ZHANG Z J. Conditional variational autoencoder informed probabilistic wind power curve modeling[J]. IEEE Transactions on Sustainable Energy, 2023, 14(4):2445-2460.
[22]	WEI D X, WANG J Z, LI Z W, et al. Wind power curve modeling with hybrid copula and grey wolf optimization[J]. IEEE Transactions on Sustainable Energy, 2022, 13(1):265-276.
[23]	LIU T H, LYU K Y, CHEN F J, et al. Wind power curve model combining smoothed spline with first-order moments and density-adjusted wind speed strategy[J]. Energy, 2024,313:133628.
[24]	郭军红, 王小萱, 汪月新, 等. Copula分位数回归方法在风电超短期出力预测上的应用[J]. 工程科学学报, 2024, 46(10): 1921-1929.
	GUO Junhong, WANG Xiaoxuan, WANG Yuexin, et al. Enhancing ultra-short-term wind power forecasting using the Copula quantile regression method[J]. Chinese Journal of Engineering, 2024, 46(10): 1921-1929.
[25]	MUSHTAQ K, WARIS A, ZOU R, et al. A comprehensive approach to wind turbine power curve modeling: Addressing outliers and enhancing accuracy[J]. Energy, 2024, 304:131981.
[26]	PICARD A, DAVIS R S, GLÄSER M, et al. Revised formula for the density of moist air (CIPM—2007)[J]. Metrologia, 2008, 45(2):149-155.
[27]	PENG C, WANG J, WU D. Impacts of air density fluctuations toward the mass measurements of a 1 kg silicon sphere[J]. IEEE Access, 2020, 8:140840-140847.

参数	单位	数值
α		1.000 62
β	Pa^-1	3.14×10^-8
γ	K^-2	5.60×10^-7

参数	单位	数值
A	K^-2	1.237 884 7×10^-5
B	K^-1	-1.912 131 6×10^-2
C		33.937 110 47
D	K	-6.343 164 5×10³

参数	单位	数值
a₀	K/Pa	1.581 23×10^-6
a₁	Pa^-1	-2.933 1×10^-8
a₂	K/Pa	1.104 3×10^-10
b₀	K/Pa	5.707 0×10^-6
b₁	Pa^-1	-2.051×10^-8
c₀	K/Pa	1.989 8×10^-4
c₁	Pa^-1	-2.376×10^-6
d	K²/Pa²	1.830×10^-11
e	K²/Pa²	-0.765×10^-8

模型	甲电场		乙电场
模型	RMSE	MAE	RMSE	MAE
Bin	2.757 7	1.603 8	4.613 9	3.166 4
PR	2.962 3	1.653 1	4.487 1	3.117 1
LI	2.515 7	1.448 8	4.456 8	3.094 1
LI-DASW	2.360 0	1.353 1	4.144 9	2.866 0

模型		Bin	PR	LI	LI-DASW
时间复杂度		O(n)	O(nk²)	O(n)	O(n)+O(1)
建模耗时/s	甲电场	0.004	0.098	0.010	0.011
建模耗时/s	乙电场	0.005	0.079	0.010	0.012
