摘要:
由于可再生能源的波动性和随机性,多区域可再生能源电力系统的负荷频率变化复杂且难以控制。为了改善电力系统的稳定性,针对多区域可再生能源电力系统的负荷频率控制问题提出了一种基于多目标遗传算法的串级自抗扰控制方法。该方法通过设计线性自抗扰控制并引入其串级结构来提高系统的抗干扰能力,借助多目标遗传算法对设计的控制器参数进行优化以减小频率和联络线功率偏差,达到更好的控制效果。此外,进行不同控制策略下电力系统的仿真和对比,结果表明所设计的控制系统具有很好的动态性能,加入负荷扰动后能够快速消除干扰并维持系统稳定。仿真结果验证了所设计控制器的有效性。
