综合智慧能源 ›› 2023, Vol. 45 ›› Issue (8): 80-89.doi: 10.3969/j.issn.2097-0706.2023.08.010
• 低碳技术经济 • 上一篇
收稿日期:
2023-04-14
修回日期:
2023-04-26
出版日期:
2023-08-25
发布日期:
2023-08-22
作者简介:
郁海彬(1990),男,工程师,硕士,从事电力调度与电力通信技术方面的研究,yuafuhan@163.com。
基金资助:
YU Haibin(), GAO Yiling, LU Zengjie, DONG Shuai, LU Lin, REN Yizhi
Received:
2023-04-14
Revised:
2023-04-26
Online:
2023-08-25
Published:
2023-08-22
Supported by:
摘要:
“双碳”目标背景下的新型能源体系既要大力发展清洁能源,又需要发挥火电的保障作用。为解决现有源、荷两侧市场机制不足以适应高比例可再生能源渗透率电网的调峰需求,构建了一种价格型需求侧响应(PBDR)下的风-火-储-碳捕集多源联合深度调峰(DPR)模型,并分析了其特性。该模型不仅解决了火电机组深度调峰损耗大、成本高、碳排放多、参与调峰积极性差等问题,而且优化了源-荷双侧出力及负荷曲线,呈现良好的削峰填谷效果,并缓解了电网的调峰压力和成本。算例表明,所建模型在提升系统风电消纳水平、降低火电机组煤耗、控制运行成本及减少深度调峰次数等方面成效显著,引入碳捕集机组参与深度调峰,进一步减少了碳排放量并促进储能参与深度调峰收益。根据火-储市场主体的成本特性考虑定价策略,实现了电网深度调峰运行的经济性和低碳性。
中图分类号:
郁海彬, 高亦凌, 陆增洁, 董帅, 鲁林, 任逸之. 计及需求响应的风-火-储-碳捕集多源参与深度调峰市场的低碳经济调度[J]. 综合智慧能源, 2023, 45(8): 80-89.
YU Haibin, GAO Yiling, LU Zengjie, DONG Shuai, LU Lin, REN Yizhi. Low-carbon economic scheduling of deep peak regulating market with the participation of wind power,thermal power,storage and carbon capture units considering demand response[J]. Integrated Intelligent Energy, 2023, 45(8): 80-89.
