计及不确定性的分布式微网参与电网优化调度方法综述

doi:10.3969/j.issn.2097-0706.2024.01.005

综合智慧能源 ›› 2024, Vol. 46 ›› Issue (1): 38-48.doi: 10.3969/j.issn.2097-0706.2024.01.005

• 基于智能算法的决策支持系统 • 上一篇下一篇

计及不确定性的分布式微网参与电网优化调度方法综述

谭九鼎¹(), 李帅兵¹^,^*(), 李明澈¹, 马喜平², 康永强¹, 董海鹰¹

1.兰州交通大学新能源与动力工程学院，兰州 730070
2.国网甘肃省电力公司电力科学研究院，兰州 730070

收稿日期:2023-06-29 修回日期:2023-08-01 出版日期:2024-01-25 发布日期:2023-09-01
通讯作者: *李帅兵（1989），男，副教授，博士，从事高压电气设备状态评估与无损检测、新能源电力系统状态检测与诊断等方面的研究，shuaibingli@mail.lzjtu.cn。
作者简介:谭九鼎（2000），男，硕士生，从事分布式微电网集群调度研究，tanjiuding66@163.com。
基金资助:
甘肃省高等学校创新基金项目(2021B-111)

Optimized scheduling of the power grid with participation of distributed microgrids considering their uncertainties

TAN Jiuding¹(), LI Shuaibing¹^,^*(), LI Mingche¹, MA Xiping², KANG Yongqiang¹, DONG Haiying¹

1. School of New Energy & Power Engineering， Lanzhou Jiaotong University， Lanzhou 730070， China
2. State Grid Gansu Electric Power Research Institute， Lanzhou 730070， China

Received:2023-06-29 Revised:2023-08-01 Online:2024-01-25 Published:2023-09-01
Supported by:
Higher Education Institutions Innovation Found Project of Gansu Province(2021B-111)

摘要/Abstract

摘要：

以高比例可再生电源为主的微网接入电力系统，在有效降低系统碳排放水平的同时，给系统带来大量不确定性因素。建立典型的“风-光-柴-储”微网结构，以经济最优、电能质量最优、碳排放最少、用户满意度最优为目标，总结了当前风、光等分布式微网电源对接入电网的主要影响。在此基础上，分别从确定模型、隶属度模型、区间数据模型3个方面总结了不确定参数建模方法，归纳了目前对含风、光不确定性电源微网优化调度的求解方法及各种方法的优缺点。最后，展望了含风、光不确定性电源微网优化调度的发展方向，旨在为微网不确定性优化调度研究提供参考。

关键词: 可再生电源, 微网, 碳排放, 随机规划模型, 鲁棒规划模型, 分布式鲁棒规划模型, 模糊规划模型

Abstract:

Connecting distributed microgrids characterized by high-proportion renewable energy to the grid system can effectively reduce the carbon emissions from the whole system， but seriously impact the stable operation for the system as well. A wind-solar-power-battery integrated system is constructed in pursuit of the optimal economy，highest quality of power，lowest carbon emissions and highest level of customer satisfaction. The negative effects of grid-connection of distributed sources， such as wind power and solar power， on the operation of power grid are summarized. Then， the uncertain parametric model for the microgrid is constructed using probabilistic model， fuzzy affiliation model， robust uncertainty set and interval-censored data set as reference. Different solutions for the optimization scheduling plans for the microgrid considering the uncertainties of renewable energy are proposed and compared. Finally， the development outlook of the power sources with uncertainties is proposed to guide the optimization scheduling of the distributed microgrids.

Key words: renewable energy, microgrid, carbon emissions, stochastic optimization scheduling model, robust optimization scheduling model, distributionaly robust optimization model, fuzzy optimization model

中图分类号:

TK019：TM727

谭九鼎, 李帅兵, 李明澈, 马喜平, 康永强, 董海鹰. 计及不确定性的分布式微网参与电网优化调度方法综述[J]. 综合智慧能源, 2024, 46(1): 38-48.

TAN Jiuding, LI Shuaibing, LI Mingche, MA Xiping, KANG Yongqiang, DONG Haiying. Optimized scheduling of the power grid with participation of distributed microgrids considering their uncertainties[J]. Integrated Intelligent Energy, 2024, 46(1): 38-48.

图/表 11

图1

表1

表2

图2

表3

典型隶属度函数及表达式

函数	函数图像	函数表达式
高斯函数		$f x, k, c = e x p - x - P 2 σ 2$
矩形函数		$μ (P) = 0 P < P 1 P 1 ≤ P ≤ P 2 0 P 2 < P$
三角函数		$μ (P) = 0 P < P 1 P 2 - P P 2 - P 1 P 1 ≤ P < P 2 1 P = P 2 P 3 - P P 3 - P 2 P 2 < P ≤ P 3 0 P > P 3$
梯形函数		$μ (P) = 0 P < P 1 P 2 - P P 2 - P 1 P 1 ≤ P < P 2 1 P 2 ≤ P ≤ P 3 P 4 - P P 4 - P 3 P 3 < P ≤ P 4 0 P > P 4$

表3

图3

图4

表4

优化调度模型及其衍生模型

模型	数学表达式
随机规划模型	$m i n / m a x F [c T y (x j)] s . t . A x j n + B x j n - 1 + ⋯ + C = 0 x j m i n ≤ x j ≤ x j m a x j = 1,2, ⋯, m$
期望值随机规划模型	$m i n / m a x F [c T y (x)] s . t . x = ∑ t = 1 n P j ω j P j ∈ P 1, P 2, ⋯, P n j = 1,2, ⋯, n$
机会约束随机规划模型	$m i n / m a x P r {F [c T y (x j)]} ≤ α s . t . A x j n ± B x j n - 1 ± ⋯ ± C = 0 x j m i n ≤ x j ≤ x j m a x j = 1,2, ⋯, m$
多阶随机规划模型	$m i n / m a x P r {F [c T y (x j)]} ≤ α s . t . A x j n ± B x j n - 1 ± ⋯ ± C = 0 x j m i n ≤ x j ≤ x j m a x j = 1,2, ⋯, m$
鲁棒规划模型	$m i n / m a x F [c T y (x, ω)] s . t . x j ∈ x j m i n, x j m a x y (x, ω) ≠ ∅ ∀ ω = (ω i), ω i ∈ ω$
多阶鲁棒规划模型	$m i n / m a x F i ⋯ m i n / m a x F 1 (c T x j) s . t . x j ∈ x j m i n, x j m a x ∀ ω = (ω i), ω i ∈ ω$
分布式鲁棒规划模型	$m i n / m a x ∑ s y s n u m = 1 n λ F n [c T y (x, ω)] s . t . x j ∈ x j m i n, x j m a x y (x, ω) ≠ ∅ ∑ λ = 1, ∀ ω = (ω i), ω i ∈ ω$
多阶分布式鲁棒规划模型	$m i n / m a x ∑ λ F i ⋯ m i n / m a x λ F 1 (c T x j) s . t . x j ∈ x j m i n, x j m a x y (x, ω) ≠ ∅ ∑ λ = 1, ∀ ω = (ω i), ω i ∈ ω$
模糊规划模型	$m i n / m a x F [g (x j)] s . t . 0 ≤ g (x j) ≤ 1 x j ∈ x j m i n, x j m a x$

表4

图5

表5

表6

参考文献 54

[1]	张沈习, 王丹阳, 程浩忠, 等. 双碳目标下低碳综合能源系统规划关键技术及挑战[J]. 电力系统自动化, 2022, 46(8):189-207.
	ZHANG Shenxi, WANG Danyang, CHENG Haozhong, et al. Key technologies and challenges of low-carbon integrated energy system planning for carbon emission peak and carbon neutrality[J]. Automation of Electric Power Systems, 2022, 46(8):189-207.
[2]	ØSTERGAARD P A, DUIC N, NOOROLLAHI Y, et al. Sustainable development using renewable energy technology[J]. Renewable Energy, 2020, 146: 2430-2437. doi: 10.1016/j.renene.2019.08.094
[3]	周任军, 闵雄帮, 童小娇, 等. 电力环保经济调度矩不确定分布鲁棒优化方法[J]. 中国电机工程学报, 2015, 35(13):3248-3256.
	ZHOU Renjun, MIN Xiongbang, TONG Xiaojiao, et al. Distributional robust optimization under moment uncertainty of environmental and economic dispatch for power system[J]. Proceedings of the CSEE, 2015, 35(13):3248-3256.
[4]	张晓辉, 闫柯柯, 卢志刚, 等. 基于场景概率的含风电系统多目标低碳经济调度[J]. 电网技术, 2014, 38(7):1835-1841.
	ZHANG Xiaohui, YAN Keke, LU Zhigang, et al. Scenario probability based multi-objective low-carbon economic dispatch for wind-containing power systems[J]. Power System Technology, 2014, 38(7):1835-1841.
[5]	ZHANG Y, GATSIS N, GIANNAKIS G B. Robust energy management for microgrids with high-penetration renewables[J]. IEEE Transactions on Sustainable Energy, 2013, 4(4): 944-953. doi: 10.1109/TSTE.2013.2255135
[6]	崔杨, 邓贵波, 赵钰婷, 等. 考虑源荷低碳特性互补的含风电电力系统经济调度[J]. 中国电机工程学报, 2021, 41(14):4799-4815.
	CUI Yang, DENG Guibo, ZHAO Yuting, et al. Economic dispatch of power system with wind power considering the complementarity of low-carbon characteristics of source side and load side[J]. Proceedings of the CSEE, 2021, 41(14):4799-4815.
[7]	刘科研, 盛万兴, 马晓晨, 等. 基于多种群遗传算法的分布式光伏接入配电网规划研究[J]. 太阳能学报, 2021, 42(6):146-155.
	LIU Keyan, SHENG Wanxing, MA Xiaochen, et al. Planning research of distributed photovoltaic source access distribution network based on multi-population genetic algorithm[J]. Acta Energiae Solaris Sinica, 2021, 42(6):146-155.
[8]	韩莹, 于三川, 李荦一, 等. 计及阶梯式碳交易的风光氢储微电网低碳经济配置方法[J]. 高电压技术, 2022, 48(7):2523-2533.
	HAN Ying, YU Sanchuan, LI Luoyi, et al. Low-carbon and economic configuration method for solar hydrogen storage microgrid including stepped carbon trading[J]. High Voltage Engineering, 2022, 48(7):2523-2533.
[9]	田明, 张海峰, 刘坤. 计及电转气和碳捕集的数据中心微电网“源-荷”低碳优化调度方法[J]. 电气工程学报, 2022, 17(3):85-94.
	TIAN Ming, ZHANG Haifeng, LIU Kun. "Source-load" low-carbon optimal scheduling method for data center microgrids considering power to gas and carbon capture[J]. Journal of Electrical Engineering, 2022, 17(3):85-94.
[10]	闫梦阳, 李华强, 王俊翔, 等. 计及综合需求响应不确定性的园区综合能源系统优化运行模型[J]. 电力系统保护与控制, 2022, 50(2):163-175.
	YAN Mengyang, LI Huaqiang, WANG Junxiang, et al. Optimal operation model of a park integrated energy system considering uncertainty of integrated demand response[J]. Power System Protection and Control, 2022, 50(2):163-175.
[11]	朱晓荣, 鹿国微, 谢婉莹. 考虑源网荷灵活性资源的配电网储能鲁棒规划[J]. 电力自动化设备, 2021, 41(8):8-16,40.
	ZHU Xiaorong, LU Guowei, XIE Wanying. Robust planning of energy storage in distribution networks considering source-network-load flexibility resources[J]. Electric Power Automation Equipment, 2021, 41(8):8-16,40.
[12]	叶泽, 李湘旗, 姜飞, 等. 考虑最优弃能率的风光火储联合系统分层优化经济调度[J]. 电网技术, 2021, 45(6):2270-2280.
	YE Ze, LI Xiangqi, JIANG Fei, et al. Hierarchical optimization economic dispatching of combined wind-PV-thermal-energy storage system considering the optimal energy abandonment rate[J]. Power System Technology, 2021, 45(6):2270-2280.
[13]	LI S, GONG W, WANG L, et al. Multi-objective optimal power flow with stochastic wind and solar power[J]. Applied Soft Computing, 2022, 114: 108045. doi: 10.1016/j.asoc.2021.108045
[14]	党媛. 大规模风电并网对电力系统电压稳定性影响的研究[D]. 兰州: 兰州理工大学, 2020.
	DANG Yuan. Research on the impact of large scale wind power grid connection on the voltage stability of power systems[D]. Lanzhou: Lanzhou University of Technology, 2020.
[15]	JITHENDRANATH J, DAS D, GUERRERO J M. Probabilistic optimal power flow in islanded microgrids with load, wind and solar uncertainties including intermittent generation spatial correlation[J]. Energy, 2021, 222: 119847. doi: 10.1016/j.energy.2021.119847
[16]	RAKIPOUR D, BARATI H. Probabilistic optimization in operation of energy hub with participation of renewable energy resources and demand response[J]. Energy, 2019, 173: 384-399. doi: 10.1016/j.energy.2019.02.021
[17]	XIE Z Q, JI T Y, LI M S, et al. Quasi-Monte Carlo based probabilistic optimal power flow considering the correlation of wind speeds using copula function[J]. IEEE Transactions on Power Systems, 2017, 33(2): 2239-2247. doi: 10.1109/TPWRS.2017.2737580
[18]	刘吉臻, 王海东, 李明扬. 含风电的电力系统机组组合问题研究综述[J]. 电力建设, 2014, 35(12):38-45. doi: 10.3969/j.issn.1000-7229.2014.12.007
	LIU Jizhen, WANG Haidong, LI Mingyang. Review on unit commitment of power systems with wind power integration[J]. Electric Power Construction, 2014, 35(12):38-45. doi: 10.3969/j.issn.1000-7229.2014.12.007
[19]	MALEKI A, KHAJEH M G, AMERI M. Optimal sizing of a grid independent hybrid renewable energy system incorporating resource uncertainty, and load uncertainty[J]. International Journal of Electrical Power & Energy Systems, 2016, 83: 514-524. doi: 10.1016/j.ijepes.2016.04.008
[20]	蒋程, 王硕, 王宝庆, 等. 基于拉丁超立方采样的含风电电力系统的概率可靠性评估[J]. 电工技术学报, 2016, 31(10):193-206.
	JIANG Cheng, WANG Shuo, WANG Baoqing, et al. Probabilistic reliability assessment of power system containing wind power based on Latin hypercube sampling[J]. Transactions of China Electrotechnical Society, 2016, 31(10):193-206.
[21]	罗钢, 石东源, 陈金富, 等. 风光发电功率时间序列模拟的MCMC方法[J]. 电网技术, 2014, 38(2):321-327.
	LUO Gang, SHI Dongyuan, CHEN Jinfu, et al. A Markov Chain Monte Carlo method for simulation of wind and solar power time series[J]. Power System Technology, 2014, 38(2):321-327.
[22]	WANG Y, HU Q, LI L, et al. Approaches to wind power curve modeling: A review and discussion[J]. Renewable and Sustainable Energy Reviews, 2019, 116: 109422. doi: 10.1016/j.rser.2019.109422
[23]	SUGANTHI L, INIYAN S, SAMUEL A A. Applications of fuzzy logic in renewable energy systems—A review[J]. Renewable and sustainable energy reviews, 2015, 48: 585-607. doi: 10.1016/j.rser.2015.04.037
[24]	向月, 刘俊勇, 魏震波, 等. 考虑可再生能源出力不确定性的微电网能量优化鲁棒模型[J]. 中国电机工程学报, 2014, 34(19):3063-3072.
	XIANG Yue, LIU Junyong, WEI Zhenbo, et al. Robust model of microgrid energy optimization with uncertain renewable energy sources[J]. Proceedings of the CSEE, 2014, 34(19):3063-3072.
[25]	YIN L F, GAO Q, ZHAO L L, et al. A review of machine learning for new generation smart dispatch in power systems[J]. Engineering Applications of Artificial Intelligence, 2020, 88: 103372. doi: 10.1016/j.engappai.2019.103372
[26]	BISWAS P P, SUGANTHAN P N, AMARATUNGA G A J. Optimal power flow solutions incorporating stochastic wind and solar power[J]. Energy Conversion and Management, 2017, 148: 1194-1207. doi: 10.1016/j.enconman.2017.06.071
[27]	WU H, SHAHIDEHPOUR M, LI Z, et al. Chance-constrained day-ahead scheduling in stochastic power system operation[J]. IEEE Transactions on Power Systems, 2014, 29(4): 1583-1591. doi: 10.1109/TPWRS.2013.2296438
[28]	DING T, LIU S Y, YUAN W, et al. A two-stage robust reactive power optimization considering uncertain wind power integration in active distribution networks[J]. IEEE Transactions on Sustainable Energy, 2015, 7(1):301-311. doi: 10.1109/TSTE.2015.2494587
[29]	ZHANG H F, YUE D, XIE X P. Robust optimization for dynamic economic dispatch under wind power uncertainty with different levels of uncertainty budget[J]. IEEE Access, 2016, 4:7633-7644. doi: 10.1109/ACCESS.2016.2621338
[30]	LORCA A, SUN X A. Adaptive robust optimization with dynamic uncertainty sets for multi-period economic dispatch under significant wind[J]. IEEE Transactions on Power Systems, 2014, 30(4): 1702-1713. doi: 10.1109/TPWRS.2014.2357714
[31]	徐秋实, 邓长虹, 赵维兴, 等. 含风电电力系统的多场景鲁棒调度方法[J]. 电网技术, 2014, 38(3):653-661.
	XU Qiushi, DENG Changhong, ZHAO Weixing, et al. A multi-scenario robust dispatch method for power grid integrated with wind farms[J]. Power System Technology, 2014, 38(3):653-661.
[32]	杨策, 孙伟卿, 韩冬, 等. 考虑风电出力不确定的分布鲁棒经济调度[J]. 电网技术, 2020, 44(10):3649-3655.
	YANG Ce, SUN Weiqin, HAN Dong, et al. Distributionally-robust economic dispatch considering uncertain wind power output[J]. Power System Technology, 2020, 44(10):3649-3655.
[33]	ALISMAIL F, XIONG P, SINGH C. Optimal wind farm allocation in multi-area power systems using distributionally robust optimization approach[J]. IEEE Transactions on Power Systems, 2017, 33(1): 536-544. doi: 10.1109/TPWRS.2017.2695002
[34]	税月, 刘俊勇, 高红均, 等. 考虑风电不确定性的电热综合系统分布鲁棒协调优化调度模型[J]. 中国电机工程学报, 2018, 38(24):7235-7247,7450.
	SHUI Yue, LIU Junyong, GAO Hongjun, et al. A distributionally robust coordinated dispatch model for integrated electricity and heating systems considering uncertainty of wind power[J]. Proceedings of the CSEE, 2018, 38(24):7235-7247,7450.
[35]	张宏, 陈钊, 黄蓉, 丁坤, 等. 风电-光伏-光热联合发电系统的模糊多目标优化模型[J]. 电源学报, 2021, 19(2):112-120. doi: 10.13234/j.issn.2095-2805.2021.2.112
	ZHANG Hong, CHEN Zhao, HUANG Rong, DING Kun, et al. Fuzzy multi-objective optimization model of wind-PV-CSP hybrid power generation system[J]. Journal of Power Supply, 2021, 19(2):112-120. doi: 10.13234/j.issn.2095-2805.2021.2.112
[36]	刘文颖, 文晶, 谢昶, 等. 基于源荷互动的含风电场电力系统多目标模糊优化调度方法[J]. 电力自动化设备, 2014, 34(10):56-63,68.
	LIU Wenyin, WEN Jing, XIE Chang, et al. Multi-objective fuzzy optimal dispatch based on source-load interaction for power system with wind farm[J]. Electric Power Automation Equipment, 2014, 34(10):56-63,68.
[37]	季峰, 蔡兴国, 岳彩国. 含风电场电力系统的模糊鲁棒优化调度[J]. 中国电机工程学报, 2014, 34(28):4791-4798.
	JI Feng, CAI Xingguo, YUE Caiguo. Fuzzy robust dispatch for power systems with wind farms[J]. Proceedings of the CSEE, 2014, 34(28):4791-4798.
[38]	LOPEZ-GARZA E, DOMINGUEZ-CRUZ R F, MARTELL-CHAVEZ F, et al. Fuzzy logic and linear programming-based power grid-enhanced economical dispatch for sustainable and stable grid operation in Eastern Mexico[J]. Energies, 2022, 15(11): 4069. doi: 10.3390/en15114069
[39]	DONG W, YANG Q, FANG X L, et al. Adaptive optimal fuzzy logic based energy management in multi-energy microgrid considering operational uncertainties[J]. Applied Soft Computing, 2021, 98: 106882. doi: 10.1016/j.asoc.2020.106882
[40]	张景瑞, 刘厚德. 基于群体智能的电力系统优化调度理论与方法[M]. 北京: 清华大学出版社, 2016.
[41]	肖白, 郭蓓. 配电网规划研究综述与展望[J]. 电力自动化设备, 2018, 38(12):200-211,217.
	XIAO Bai, GUO Bei. Review and prospect of distribution network planning[J]. Electric Power Automation Equipment, 2018, 38(12):200-211,217.
[42]	刘吉臻, 王海东, 李明扬. 含风电的电力系统机组组合问题研究综述[J]. 电力建设, 2014, 35(12):38-45. doi: 10.3969/j.issn.1000-7229.2014.12.007
	LIU Jizhen, WANG Haidong, LI Mingyang. Review on unit commitment of power systems with wind power integration[J]. Electric Power Construction, 2014, 35(12):38-45. doi: 10.3969/j.issn.1000-7229.2014.12.007
[43]	MAHMOOD A R, VAN HASSELT H P, SUTTON R S. Weighted importance sampling for off-policy learning with linear function approximation[J]. Advances in Neural Information Processing Systems, 2014, 27.
[44]	PEYGHAMI M R, HAFSHEJANI S F, SHIRVANI L. Complexity of interior-point methods for linear optimization based on a new trigonometric kernel function[J]. Journal of Computational and Applied Mathematics, 2014, 255: 74-85. doi: 10.1016/j.cam.2013.04.039
[45]	VARAGNOLO D, ZANELLA F, CENEDESE A, et al. Newton-Raphson consensus for distributed convex optimization[J]. IEEE Transactions on Automatic Control, 2015, 61(4): 994-1009. doi: 10.1109/TAC.2015.2449811
[46]	何小宇, 张粒子, 谢国辉. 改进的拉格朗日松弛法求解机组组合问题[J]. 电力系统保护与控制, 2010, 38(17):16-21.
	HE Xiaoyu, ZHANG Lizi, XIE Guohui. Unit commitment using an improved Lagrangian relaxation method[J]. Power System Protection and Control, 2010, 38(17):16-21.
[47]	龙军, 莫群芳, 曾建. 基于随机规划的含风电场的电力系统节能优化调度策略[J]. 电网技术, 2011, 35(9):133-138.
	LONG Jun, MO Qunfang, ZENG Jian. A stochastic programming based short-term optimization scheduling strategy considering energy conservation for power system containing wind farms[J]. Power System Technology, 2011, 35(9):133-138.
[48]	RAHMANIANI R, CRAINIC T G, GENDREAU M, et al. The Benders decomposition algorithm: A literature review[J]. European Journal of Operational Research, 2017, 259(3): 801-817. doi: 10.1016/j.ejor.2016.12.005
[49]	ZENG B, ZHAO L. Solving two-stage robust optimization problems using a column-and-constraint generation method[J]. Operations Research Letters, 2013, 41(5): 457-461. doi: 10.1016/j.orl.2013.05.003
[50]	张海波, 申杰, 王国荣, 等. 考虑无功设备动作的交直流电网日前两阶段随机优化调度[J]. 电力系统自动化, 2022, 46(8):133-142.
	ZHANG Haibo, SHEN Jie, WANG Guorong, et al. Day-ahead two-stage stochastic optimal dispatch of AC/DC power grid considering reactive power equipment operation[J]. Automation of Electric Power Systems, 2022, 46(8):133-142.
[51]	崔杨, 郭福音, 仲悟之, 等. 多重不确定性环境下的综合能源系统区间多目标优化调度[J]. 电网技术, 2022, 46(8):2964-2975.
	CUI Yang, GUO Fuyin, ZHONG Wuzhi, et al. Interval multi-objective optimal dispatch of integrated energy system under multiple uncertainty environment[J]. Power System Technology, 2022, 46(8):2964-2975.
[52]	王守相, 王栋, 韩亮. 考虑不确定性的微网日前经济优化调度区间线性规划方法[J]. 电力系统自动化, 2014, 38(24):5-11,47.
	WANG Shouxiang, WANG Dong, HAN Liang. Interval linear programming method for day-ahead optimal economic dispatching of microgrid considering uncertainty[J]. Automation of Electric Power Systems, 2014, 38(24):5-11,47.
[53]	刘子祺, 苏婷婷, 何佳阳, 等. 基于多目标粒子群算法的配电网储能优化配置研究[J]. 综合智慧能源, 2023, 45(6): 9-16. doi: 10.3969/j.issn.2097-0706.2023.06.002
	LIU Ziqi, SU Tingting, HE Jiayang, et al. Research on the optimal allocation of energy storage in distribution network based on multi-objective particle swarm optimization algorithm[J]. Integrated Intelligent Energy, 2023, 45(6): 9-16. doi: 10.3969/j.issn.2097-0706.2023.06.002
[54]	王永林, 白永峰, 孔祥山, 等. 基于CNN-LSTM算法的脱硝优化控制模型研究[J]. 综合智慧能源, 2023, 45(6): 25-33. doi: 10.3969/j.issn.2097-0706.2023.06.004
	WANG Yonglin, BAI Yongfeng, KONG Xiangshan, et al. Study on denitration optimization control model based on CNN-LSTM algorithm[J]. Integrated Intelligent Energy, 2023, 45(6): 25-33. doi: 10.3969/j.issn.2097-0706.2023.06.004

优化目标	研究内容	研究特点
经济最优	经济性最优调度^[3]	改进粒子群算法求解
	经济优化子问题与经济优化主问题多重优化^[4]	不确定场景集概率模型、粒子群算法求解
	考虑高比例绿电并网的系统鲁棒性提升消纳率^[5]	对偶分解为多子系统，利用本地搜寻求解
	结合碳减排目标结合多目标调度^[6]	同时考虑电源侧与负荷侧两端数据变化开展多能互补
电能质量最优	综合经济性规划兼顾电网安全性优化^[7]	多种群遗传算法求解
碳排放最优	阶梯碳交易机制、分时电价结合优化微电网成本与系统碳排放^[8]	粒子群算法求解
碳排放最优	添加碳捕集设备并联合调度实现成本、碳排放最优化^[9]	随机规划模型、多目标求解
用户满意度最优	考虑用户功率需求不确定性开展调度^[10]	区间线性规划
多目标协同优化	潮流计算、多目标嵌套、储能灵活优化^[11]	不确定场景集合、鲁棒优化、复合差分进化算法求解
	能量损耗最小、最优经济性、调峰调度^[12]	双层优化调度、线性规划求解
	最小化节点电压降、最小化碳排放、最小化网损^[13]	二代非支配排序遗传算法（NSGA-II）求解

随机采样方法	结合原理	应用优势
蒙特卡洛	随机采样	生成随机场景，利用特殊场景表示数据总体数据特征
序列蒙特卡洛	递推逼近	利用递推逼近，可使模型具有自适应能力
重要性采样	加权分配	引入权重系数，可全局考虑历史数据特征
拉丁超立方	均匀、分层采样原理	分段采样确保样本不重叠，场景均匀分布
拟蒙特卡洛	低差异率列采样	尽量多地填充单位超立方利用数量提升精度
马尔科夫链蒙特卡洛	马尔科夫链、场景树	可实现动态场景随机模拟

算法	初值选取	计算速度	结果
常规算法	除非线性算法外其他算法均严格要求参数保持线性	线性规划算法速度较快，非线性规划、混合整数规划法速度较慢，动态规划计算速度慢	动态规划通过分段求解可得到全局最优解，其他算法均不同程度陷入次优解
启发式算法	除遗传算法、禁忌算法外其他算法对参数有不同程度的线性要求	禁忌搜索算法、粒子群优化算法减速度快；退火算法、遗传算法求解速度较慢且计算过程随机化程度高,难以控制	退火算法、粒子群算法逼近全局最优解能力较好；禁忌算法、遗传算法结果优劣取决于预先设置的参数，否则易陷入次优解
组合式算法	需要根据算法选取数据	计算精度、计算速度均具优势	均能得到全局最优解，其中改进粒子群算法全局性最优

算法	实施方法	特点
线性规划	Lamda迭代法^[43]	迭代至误差小于人工设定参数λ
线性规划	内点法^[44]	向目标函数最快下降方向搜寻收敛最优解
非线性规划	牛顿法^[45]	一阶雅可比与二阶海森矩阵实现梯度下降
	拉格朗日算法^[46]	分解多约束主问题为子问题依次优化计算
	二次规划法^[47]	泰勒级数重构目标函数形成二次函数
混合整数规划	Benders算法^[48]	主次问题逐次迭代并修正参数逼近最优解
混合整数规划	C&CG算法^[49]	结合对偶理论转化主、子问题简化计算
动态规划		基于时序或空间分解主问题为子问题求解
