铁锰改性油茶壳基生物炭对污泥厌氧消化性能及微生物群落结构的影响

doi:10.3969/j.issn.2097-0706.2024.08.006

综合智慧能源 ›› 2024, Vol. 46 ›› Issue (8): 41-49.doi: 10.3969/j.issn.2097-0706.2024.08.006

铁锰改性油茶壳基生物炭对污泥厌氧消化性能及微生物群落结构的影响

罗坤¹^,²(), 朱艺¹^,^*(), 黄兢²^,^*(), 李辉¹^,²()

1.长江大学资源与环境学院，武汉 430100
2.湖南省林业科学院省部共建木本油料资源利用国家重点实验室，长沙 410004

收稿日期:2024-03-06 修回日期:2024-04-01 出版日期:2024-08-25
通讯作者: 朱艺（1982），男，副教授，博士，从事环境污染控制与生态修复方面的研究，zhuyi0731@126.com。
*黄兢（1984），男，副研究员，博士，从事农林剩余物及城市固体废物资源化、湿地及矿区修复等方面的研究，gavinhj@163.com；
作者简介:罗坤（1997），男，硕士生，从事污泥厌氧消化方面的研究，1490899790@qq.com；
李辉（1983），男，研究员，博士，从事生物质资源化、湿地修复、重金属污染土壤修复等方面的研究，lihuiluoyang@163.com。
基金资助:
湖南省杰出青年基金项目(2023JJ10023);长沙市自然科学基金项目(kq2208101)

Impact of iron-manganese modified Camellia oleifera shell-based biochar on the anaerobic digestion performance and microbial community structure of sludge

LUO Kun¹^,²(), ZHU Yi¹^,^*(), HUANG Jing²^,^*(), LI Hui¹^,²()

1. College of Resources and Environment， Yangtze University， Wuhan 430100， China
2. State Key Laboratory of Utilization of Woody Oil Resource， Hunan Academy of Forestry， Changsha 410004， China

Received:2024-03-06 Revised:2024-04-01 Published:2024-08-25
Supported by:
Hunan Outstanding Youth Fund(2023JJ10023);Changsha Natural Science Foundation(kq2208101)

摘要/Abstract

摘要：

水解阶段是污泥厌氧消化的限速阶段，投加外源添加剂生物炭（BC）是打破水解限制与提高甲烷产量的有效手段。以木本油料加工剩余物油茶壳为原料，制备铁锰改性生物炭（Fe-Mn-BC），并通过扫描电镜、傅里叶变换红外光谱仪、X射线光电子能谱、X射线衍射仪等对材料进行表征测试，探讨其对污泥厌氧消化性能、甲烷产量以及微生物群落结构的影响。结果表明：Fe-Mn-BC具有多孔结构，铁锰颗粒以多种氧化物的形式负载在BC表面；添加Fe-Mn-BC能提高甲烷产量，当投加的Fe-Mn-BC总固体质量分数为80 mg/g时，累积产气量最高达301.59 mL/g，较未添加组提升了45.27%。微生物群落分析发现，添加Fe-Mn-BC的组别古菌群落优势菌泉古菌门（Crenarchaeota）、Candidatus_Methanomethylicus和Candidatus_Methanofastidiosum丰度增加，这些菌群能有效促进有机物水解并提高甲烷产量，表明Fe-Mn-BC的加入不仅能富集产甲烷菌等具有功能性的微生物菌群，有效提高污泥厌氧消化效率，也为油茶壳的资源化利用提供了有效途径。

关键词: 厌氧消化, 污泥, 油茶壳, 铁锰改性生物炭, 微生物群落, 甲烷, 水解

Abstract:

Hydrolysis process limits the anaerobic digestion （AD） rate of sludge. Supplementing exogenous biochar （BC） can effectively boost methane production by overcoming the limitation in hydrolysis. The iron-manganese modified biochar （Fe-Mn-BC） derived from the residual shells of woody oil crops， specifically Camellia oleifera shells， is studied. SEM， FTIR， XPS and XRD are employed to characterize the material， and its impacts on sludge AD performance， methane yield and microbial community structure are explored. The study results demonstrate that since Fe-Mn-BC possesses a porous structure， iron and manganese particles can load onto the BC surface in various forms of oxides. The addition of Fe-Mn-BC elevates methane production. When the total solid mass fraction of Fe-Mn-BC reaches 80 mg/g， cumulative gas production peaks at 301.59 mL/g， marking a 45.27% increase compared to that of the control group. Microbial community analysis reveals that Fe-Mn-BC enriches the abundance of archaeal communities， including Crenarchaeota， Candidatus_Methanomethylicus and Candidatus_Methanofastidiosum. These communities play crucial roles in promoting the hydrolysis of organic matters and enhancing the methane production， indicating that Fe-Mn-BC not only enriches functional microbial communities such as methanogenic bacteria， but also effectively improves the efficiency of sludge AD. Furthermore， this method presents a resource utilization solution for Camellia oleifera shells.

Key words: anaerobic digestion, sludge, Camellia oleifera shell, iron-manganese modified biochar, microbial community, methane, hydrolysis

中图分类号:

TK09：X705

罗坤, 朱艺, 黄兢, 李辉. 铁锰改性油茶壳基生物炭对污泥厌氧消化性能及微生物群落结构的影响[J]. 综合智慧能源, 2024, 46(8): 41-49.

LUO Kun, ZHU Yi, HUANG Jing, LI Hui. Impact of iron-manganese modified Camellia oleifera shell-based biochar on the anaerobic digestion performance and microbial community structure of sludge[J]. Integrated Intelligent Energy, 2024, 46(8): 41-49.

图/表 10

表1

图1

表2

图2

图3

图4

图5

图6

表3

图7

参考文献 30

[1]	童家麟, 张岩, 刘文胜, 等. 对冲燃烧锅炉掺烧污泥炉内燃烧及碱金属分布模拟研究[J/OL]. 综合智慧能源, 2023:1-9(2024-03-01)[2023-08-22]. https://kns.cnki.net/kcms2/article/abstract?v=ttOPOQ75YvIpq2efWJFMQA9cd07-A3-zxkdO7mBauUCMV6lg1fdiGSO4w7XLTlKbcn2cLil7BFcxh_i070A_mE4OxFFrvCbMDG0YohrgGOU9zFi_619aWQYmcbIyGg_CxQrDHkykI68=&uniplatform=NZKPT&language=CHS.
	TONG Jialin, ZHANG Yan, LIU Wensheng, et al. Simulation study on combustion and distribution of alkali metals in a mixed sludge furnace of a counter combustion boiler[J/OL]. Integrated Intelligent Energy, 2023:1-9(2024-03-01)[2023-08-22]. https://kns.cnki.net/kcms2/article/abstract?v=ttOPOQ75YvIpq2efWJFMQA9cd07-A3-zxkdO7mBauUCMV6lg1fdiGSO4w7XLTlKbcn2cLil7BFcxh_i070A_mE4OxFFrvCbMDG0YohrgGOU9zFi_619aWQYmcbIyGg_CxQrDHkykI68=&uniplatform=NZKPT&language=CHS.
[2]	YANG W, CAI C, YANG D H, et al. Implications for assessing sludge hygienization: Differential responses of the bacterial community, human pathogenic bacteria, and fecal indicator bacteria to sludge pretreatment-anaerobic digestion[J]. Journal of Hazardous Materials, 2023, 443: 130110.
[3]	胡玮麟, 谭梦娇, 朱艺, 等. 生物质储藏技术研究进展[J]. 综合智慧能源, 2023, 45(5): 80-85. doi: 10.3969/j.issn.2097-0706.2023.05.009
	HU Weilin, TAN Mengjiao, ZHU Yi, et al. Research progress of biomass storage technologies[J]. Integrated Intelligent Energy, 2023, 45(5): 80-85. doi: 10.3969/j.issn.2097-0706.2023.05.009
[4]	LI C W, LE-MINH N, MCDONALD J A, et al. Occurrence and risk assessment of trace organic contaminants and metals in anaerobically co-digested sludge[J]. Science of the Total Environment, 2022, 816: 151533.
[5]	蒋雨辰, 李清扬, 胡勋. 基于微波热解技术制备生物炭的研究进展[J]. 综合智慧能源, 2023, 45(5): 46-62. doi: 10.3969/j.issn.2097-0706.2023.05.006
	JIANG Yuchen, LI Qingyang, HU Xun. Research progress of biochar prepared by microwave pyrolysis technology[J]. Integrated Intelligent Energy, 2023, 45(5): 46-62. doi: 10.3969/j.issn.2097-0706.2023.05.006
[6]	范友华, 喻宁华, 邓腊云, 等. 氧化镁负载的油茶壳基生物炭的制备及其吸附镉性能研究[J]. 湖南林业科技, 2019, 46(3): 1-8.
	FAN Youhua, YU Ninghua, DENG Layun, et al. Cadmium removal from aqueous solution by magnesium oxide embedded biochar composites[J]. Hunan Forestry Science & Technology, 2019, 46(3): 1-8.
[7]	孙韫理, 李志钢, 周波. 过滤对压榨油茶籽油抗氧化稳定性的影响研究[J]. 湖南林业科技, 2021, 48(5): 22-27.
	SUN Yunli, LI Zhigang, ZHOU Bo. Effect of filtration on the antioxidant stability of pressed Camellia seed oil[J]. Hunan Forestry Science & Technology, 2021, 48(5): 22-27.
[8]	XIE B H, GONG W J, TANG X B, et al. Blending high concentration of anaerobic digestion effluent and rainwater for cost-effective Chlorella vulgaris cultivation in the photobioreactor[J]. Chemical Engineering Journal, 2019, 360: 861-865.
[9]	ZHANG J S, FAN C F, ZHAO W Q, et al. Improving bio-H₂ production by manganese doped magnetic carbon[J]. International Journal of Hydrogen Energy, 2019, 44(49): 26920-26932.
[10]	方健梅, 蒋丽伟, 杨帆, 等. 施用生物炭对国槐人工林土壤理化性质的影响[J]. 湖南林业科技, 2023, 50(2): 14-19.
	FANG Jianmei, JIANG Liwei, YANG Fan, et al. Effects of biochar application on physical and chemical properties of Sophora japonica plantation soil[J]. Hunan Forestry Science & Technology, 2023, 50(2): 14-19.
[11]	何修丹, 余家琳, 陶悦, 等. 不同类型催化剂活化过硫酸盐降解水中有机污染物的研究进展[J]. 环境污染与防治, 2021, 43(10): 1344-1349.
	HE Xiudan, YU Jialin, TAO Yue, et al. Research progress on the degradation of organic pollutants in water by persulfate activated with different catalysts[J]. Environmental Pollution & Control, 2021, 43(10): 1344-1349.
[12]	JIANG L, ZHANG Y R, ZHU Y, et al. Effects of magnetic biochar addition on mesophilic anaerobic digestion of sewage sludge[J]. International Journal of Environmental Research and Public Health, 2023, 20(5): 4278.
[13]	王江南, 孙晓雪, 杨玲辉, 等. 壳聚糖、铁锰改性稻壳生物炭的表征及其Cd²⁺吸附性能研究[J]. 农业环境科学学报, 2023, 42(9): 1964-1973.
	WANG Jiangnan, SUN Xiaoxue, YANG Linghui, et al. Characterization of chitosan,Fe-Mn-modified rice husk biochar and its Cd²⁺ adsorption performance[J]. Journal of Agro-Environment Science, 2023, 42(9): 1964-1973.
[14]	冉钟吕, 苍岩, 戴晨, 等. 生物炭负载铁锰氧化物吸附去除Cr(Ⅵ)的试验研究[J]. 工业用水与废水, 2022, 53(4): 28-33.
	RAN Zhonglv, CANG Yan, DAI Chen, et al. Experimental study on removal of Cr(Ⅵ)by adsorption of iron and manganese oxides supported by biochar[J]. Industrial Water & Wastewater, 2022, 53(4): 28-33.
[15]	ZHANG Z G, CHENG Q, HUANG J, et al. Production of biochar from the combination of foaming drying and pyrolysis of sludge with the additive of Camellia oleifera shell biochar[J]. Journal of Analytical and Applied Pyrolysis, 2021, 160: 105350.
[16]	李江东, 刘润龙, 李欣, 等. 铁锰氧化物-生物炭复合材料对Pb²⁺的吸附研究[J]. 中北大学学报(自然科学版), 2023, 44 (5): 550-554.
	LI Jiangdong, LIU Runlong, LI Xin, et al. Study on Adsorption of Pb²⁺ by Fe-Mn oxides biochar composites[J]. Journal of North University of China(Natural Science Edition), 2023, 44 (5): 550-554.
[17]	LI J H, ZHANG M, YE Z Y, et al. Effect of manganese oxide-modified biochar addition on methane production and heavy metal speciation during the anaerobic digestion of sewage sludge[J]. Journal of Environmental Sciences, 2019, 76: 267-277. doi: S1001-0742(18)30102-5 pmid: 30528018
[18]	ZHANG M, WANG Y C. Effects of Fe-Mn-modified biochar addition on anaerobic digestion of sewage sludge: Biomethane production, heavy metal speciation and performance stability[J]. Bioresource Technology, 2020, 313: 123695.
[19]	HE C S, DING R R, CHEN J Q, et al. Interactions between nanoscale zero valent iron and extracellular polymeric substances of anaerobic sludge[J]. Water Research, 2020, 178: 115817.
[20]	阮仁俊, 余成龙, 李祎多, 等. 花生壳磁性生物炭对颜料污泥厌氧消化及重金属形态的影响[J]. 农业工程学报, 2022, 38(9): 261-267.
	RUAN Renjun, YU Chenglong, LI Yiduo, et al. Effects of peanut shell magnetic biochar on anaerobic digestion of pigment sludge and heavy metal speciation[J]. Transactions of the Chinese Society of Agricultural Engineering, 2022, 38(9): 261-267.
[21]	JIN H Y, YANG L, REN Y X, et al. Insights into the roles and mechanisms of a green-prepared magnetic biochar in anaerobic digestion of waste activated sludge[J]. Science of the Total Environment, 2023, 896: 165170.
[22]	ZHANG G Y, SHI Y H, ZHAO Z S, et al. Enhanced two-phase anaerobic digestion of waste-activated sludge by combining magnetite and zero-valent iron[J]. Bioresource Technology, 2020, 306: 123122.
[23]	LIZAMA A C, FIGUEIRAS C C, PEDREGUERA A Z, et al. Enhancing the performance and stability of the anaerobic digestion of sewage sludge by zero valent iron nanoparticles dosage[J]. Bioresource Technology, 2019, 275: 352-359. doi: S0960-8524(18)31757-7 pmid: 30597397
[24]	LIU X R, WU Y X, XU Q X, et al. Mechanistic insights into the effect of poly ferric sulfate on anaerobic digestion of waste activated sludge[J]. Water Research, 2021, 189: 116645.
[25]	SPEIRS L B M, RICE D T F, PETROVSKi S, et al. The phylogeny, biodiversity, and ecology of the chloroflexi in activated sludge[J]. Frontiers in Microbiology, 2019, 10:2015.
[26]	CHEN Y W, YANG Z H, ZHANG Y R, et al. Effects of different conductive nanomaterials on anaerobic digestion process and microbial community of sludge[J]. Bioresource Technology, 2020, 304: 123016.
[27]	FENG Y H, ZHANG Y B, QUAN X, et al. Enhanced anaerobic digestion of waste activated sludge digestion by the addition of zero valent iron[J]. Water Research, 2014, 52: 242-250. doi: 10.1016/j.watres.2013.10.072 pmid: 24275106
[28]	JIANG M T, JI S H, WU R X, et al. Exploiting refractory organic matter for advanced nitrogen removal from mature landfill leachate via anammox in an expanded granular sludge bed reactor[J]. Bioresource Technology, 2023, 371: 128594.
[29]	ZHONG Y J, HE J G, ZHANG P F, et al. Effects of different particle size of zero-valent iron (ZVI) during anaerobic digestion: Performance and mechanism from genetic level[J]. Chemical Engineering Journal, 2022, 435: 134977.
[30]	HAO X D, WEI J, VAN L M C M, et al. Analysing the mechanisms of sludge digestion enhanced by iron[J]. Water Research, 2017, 117: 58-67. doi: S0043-1354(17)30232-4 pmid: 28390236

参数	单位	接种污泥	基质污泥
pH值		7.34±0.06	7.42±0.03
TS	g/L	13.62±0.13	79.85±0.46
VS	g/L	5.36±0.04	42.58±0.32
SCOD	mg/L	472.83±26.29	6 183.74±89.15
可溶性蛋白质量浓度	mg/L	43.57±2.49	395.76±2.81
可溶性多糖质量浓度	mg/L	34.59±6.83	402.65±8.22

样品	组成元素的质量分数/%					S_BET/（m²·g^-1）
样品	C	N	O	Fe	Mn	S_BET/（m²·g^-1）
BC	86.43	4.74	8.84	—	—	2.81
Fe-Mn-BC	65.03	—	21.25	7.50	1.92	18.29

试验组	Shannon指数		Simpson指数		Chao1指数		覆盖度
试验组	细菌	古菌	细菌	古菌	细菌	古菌	细菌	古菌
H0	2.558	1.164	0.112	0.361	53.5	8.0	0.999	1.000
H1	2.495	1.234	0.114	0.330	54.5	7.0	0.999	1.000
H2	2.651	1.254	0.100	0.330	51.0	8.0	0.999	1.000
H3	2.681	1.323	0.100	0.313	53.0	8.0	0.999	0.999
H4	2.746	1.462	0.098	0.272	57.0	10.0	0.999	0.999
H5	2.708	1.433	0.099	0.298	56.3	9.0	0.999	0.999
