Research progress on PVACs and their application in buildings

doi:10.3969/j.issn.2097-0706.2026.04.001

Abstract

Abstract:

Photovoltaic-driven air conditioning （PVAC） systems offer a new approach to reducing building energy consumption and advancing carbon neutrality by integrating renewable energy with building thermal management capabilities. The technical principles and classification characteristics of PVAC systems are systematically reviewed， and their driving mechanisms are categorized into three main types： AC-driven， DC-direct-driven， and hybrid-driven. The research progress on PVAC in terms of energy transfer optimization， dynamic control strategies， and multi-parameter collaborative design is presented. It is demonstrated that the optimized PVAC systems can achieve efficient matching of photovoltaic power generation and refrigeration demand in high-temperature regions in summer， with energy consumption coverage of air conditioning increasing to 29.5%. Furthermore， the system scheme integrating phase change materials and variable-speed compressors can significantly increase the real-time zero energy probability. The integration of PVAC systems with buildings （i.e.， building-integrated photovoltaics） can not only enhance building performance but also improve the energy utilization efficiency of PVAC systems. However， there is still a lack of a unified evaluation indicator system for building-integrated photovoltaic systems. Future research is expected to provide new insights into improving PVAC system performance and promoting their large-scale application in buildings.

Key words: photovoltaic-driven air conditioning, building energy efficiency, parameter characteristics and evaluation indicator, control strategy, building-integrated photovoltaics

CLC Number:

TK01：TU18

CAI Yang, ZHENG Shanle, HUANG Yingxi, LIU Ziquan, AN Rongbang. Research progress on PVACs and their application in buildings[J]. Integrated Intelligent Energy, 2026, 48(4): 1-11.

Figures/Tables 6

Fig.1

Table 1

Fig.2

Fig.3

Table 2

Research results of typical PVAC system parameters

分类	参数	主要结论	分析方法	评价指标	参考文献
光伏参数	光伏容量	当P_PV（t）/L（t）=1时，性能最佳	数值分析	SCR，SSR，COP	[13]
	工作温度	温度升高会导致电荷载流子的迁移率降低，进而降低电池效率	数值分析	光伏电池温度	[38]
		工作温度每升高1 ℃，光电转换效率会降低0.08%~0.10%，输出电功率下降0.45%	试验测试	光电转换效率、输出电功率	[37]
		工作温度升高，光伏性能会降低	综述总结	光电转换效率、温度系数	[44]
	光伏材料	第一代为硅电池，第二代为薄膜电池，第三代为高效电池	综述总结	光电转换效率	[43]
	光伏倾角	在非理想位置下存在能量损失	数值分析	能量损失百分比	[47]
	MPPT类型	分为HC，INC，P&O和FLC，其中FLC表现最佳	数值模拟	动态响应性能、稳态性能	[46]
空调参数	压缩机类型	变速压缩系统在制冷和制热模式下分别实现50%和16%的能效提升	试验测试	熵效率、单位投资成本	[45]
空调参数	逆变器效率	需低温运行，受光伏输入功率影响较大，在特定辐照下效率可达最高	数值分析	辐照度分布、光伏组件技术	[48]
环境参数	辐照度	太阳辐照度增加，光伏发电效率增加	试验测试	光电转换效率、SSR	[15]
	季节	光伏系统在冬季的输出电功率相比夏季有所降低	数值模拟	输出电功率、光电转换效率	[49]
	风	风载荷使组件表面压力非均匀分布，降低光伏系统性能	试验测试	表面均压	[50]
	局部遮挡	局部遮挡会显著降低光伏系统的功率输出和效率	综述总结	能量获取效率	[51]
	空气污染	中国西部城市，气溶胶污染在2014—2018年年均减少4.8%~9.0%的光伏发电量	试验测试	输出电功率、收益	[52]
		空气污染显著降低光伏发电量	数值分析	输出电功率、收益	[53]
		污染物将减小透射率，降低光伏发电效率	综述总结	输出电效率	[54]

Table 2

Table 3

References 81

[1]	邹风华, 朱星阳, 殷俊平, 等. “双碳”目标下建筑能源系统发展趋势分析[J]. 综合智慧能源, 2024, 46(8): 36-40. doi: 10.3969/j.issn.2097-0706.2024.08.005
	ZOU Fenghua, ZHU Xingyang, YIN Junping, et al. Development trend analysis on building energy systems under "dual carbon" target[J]. Integrated Intelligent Energy, 2024, 46(8): 36-40. doi: 10.3969/j.issn.2097-0706.2024.08.005
[2]	中国建筑节能协会, 重庆大学城乡建设与发展研究院. 中国建筑能耗与碳排放研究报告(2022年)[J]. 建筑, 2023(2): 57-69.
	CABEE, IURCD. Research report on building energy consumption and carbon emissions in China (2022)[J]. Construction and Architecture, 2023(2): 57-69.
[3]	YOON J H, BALDICK R, NOVOSELAC A. Dynamic demand response controller based on real-time retail price for residential buildings[J]. IEEE Transactions on Smart Grid, 2014, 5(1): 121-129. doi: 10.1109/TSG.2013.2264970
[4]	蔡阳, 黄颖茜, 黄晓燕, 等. 光伏-相变耦合系统及其建筑应用研究进展[J]. 建筑科学, 2024, 40(4):116-127,133.
	CAI Yang, HUANG Yingxi, HUANG Xiaoyan, et al. Research progress of PV-PCM system and its building application[J]. Building Science, 2024, 40(4): 116-127, 133.
[5]	EICKER U, PIETRUSCHKA D, SCHMITT A, et al. Comparison of photovoltaic and solar thermal cooling systems for office buildings in different climates[J]. Solar Energy, 2015, 118: 243-255. doi: 10.1016/j.solener.2015.05.018
[6]	FONG K F, CHOW T T, LEE C K, et al. Comparative study of different solar cooling systems for buildings in subtropical city[J]. Solar Energy, 2010, 84(2): 227-244. doi: 10.1016/j.solener.2009.11.002
[7]	HUANG B J, HOU T F, HSU P C, et al. Design of direct solar PV driven air conditioner[J]. Renewable Energy, 2016, 88: 95-101. doi: 10.1016/j.renene.2015.11.026
[8]	LI Y, ZHANG G, LYU G Z, et al. Performance study of a solar photovoltaic air conditioner in the hot summer and cold winter zone[J]. Solar Energy, 2015, 117: 167-179. doi: 10.1016/j.solener.2015.04.015
[9]	LIU Z B, LI A, WANG Q H, et al. Performance study of a quasi grid-connected photovoltaic powered DC air conditioner in a hot summer zone[J]. Applied Thermal Engineering, 2017, 121: 1102-1110. doi: 10.1016/j.applthermaleng.2017.03.132
[10]	AGUILAR F J, ALEDO S, QUILES P V. Experimental analysis of an air conditioner powered by photovoltaic energy and supported by the grid[J]. Applied Thermal Engineering, 2017, 123: 486-497. doi: 10.1016/j.applthermaleng.2017.05.123
[11]	张思亮, 祁麟童, 曲浩维, 等. 光伏发电辅助空气源热泵供暖系统研究[J]. 综合智慧能源, 2023, 45(12): 10-19. doi: 10.3969/j.issn.2097-0706.2023.12.002
	ZHANG Siliang, QI Lintong, QU Haowei, et al. Research on solar assisted air source heat pump heating systems[J]. Integrated Intelligent Energy, 2023, 45(12): 10-19. doi: 10.3969/j.issn.2097-0706.2023.12.002
[12]	靳肖林, 文尚胜, 倪浩智, 等. 光伏发电系统最大功率点跟踪技术综述[J]. 电源技术, 2019, 43(3): 532-535.
	JIN Xiaolin, WEN Shangsheng, NI Haozhi, et al. Review of maximum power point tracking of photovoltaic system[J]. Chinese Journal of Power Sources, 2019, 43(3): 532-535.
[13]	LI H P, LI J, LI S H, et al. Matching characteristics and AC performance of the photovoltaic-driven air conditioning system[J]. Energy, 2023, 264: 126509. doi: 10.1016/j.energy.2022.126509
[14]	ZHAO B Y, LI Y, WANG R Z, et al. A universal method for performance evaluation of solar photovoltaic air-conditioner[J]. Solar Energy, 2018, 172: 58-68. doi: 10.1016/j.solener.2018.05.029
[15]	ATLASON R S, GIACALONE D, PARAJULY K. Product design in the circular economy: Users' perception of end-of-life scenarios for electrical and electronic appliances[J]. Journal of Cleaner Production, 2017, 168: 1059-1069. doi: 10.1016/j.jclepro.2017.09.082
[16]	DAGNACHEW A G, LUCAS P L, HOF A F, et al. Trade-offs and synergies between universal electricity access and climate change mitigation in Sub-Saharan Africa[J]. Energy Policy, 2018, 114: 355-366. doi: 10.1016/j.enpol.2017.12.023
[17]	TULPULE P J, MARANO V, YURKOVICH S, et al. Economic and environmental impacts of a PV powered workplace parking garage charging station[J]. Applied Energy, 2013, 108: 323-332. doi: 10.1016/j.apenergy.2013.02.068
[18]	AL-ALILI A. A hybrid air conditioner driven by a hybrid solar collector[D]. Washington D C: University of Maryland, College Park, 2012.
[19]	吕光昭. 独立光伏空调系统的研究[D]. 上海: 上海交通大学, 2012.
	LYU Guangzhao. Research on a stand-alone photovoltaic air conditioning system[D]. Shanghai: Shanghai Jiao Tong University, 2012.
[20]	LIU Z B, WANG B H, YANG S. Experimental investigation of a solar photovoltaic DC refrigerator with cold storage[J]. Advanced Materials Research, 2012, 550: 3103-3107.
[21]	SANNINO A, POSTIGLIONE G, BOLLEN M H J. Feasibility of a DC network for commercial facilities[C]// Conference Record of the 2002 IEEE Industry Applications Conference. IEEE, 2002.
[22]	SABRY A H, SHALLAL A H, HAMEED H S, et al. Compatibility of household appliances with DC microgrid for PV systems[J]. Heliyon, 2020, 6(12): e05699. doi: 10.1016/j.heliyon.2020.e05699
[23]	GLASGOB, AZEVEDOI L, HENDRICKSONC. How much electricity can we save by using direct current circuits in homes?Understanding the potential for electricity savings and assessing feasibility of a transition towards DC powered buildings[J]. Applied Energy, 2016, 180: 66-75. doi: 10.1016/j.apenergy.2016.07.036
[24]	SABRY A H, KER P J. DC environment for a refrigerator with variable speed compressor; power consumption profile and performance comparison[J]. IEEE Access, 2020, 8: 147973-147982. doi: 10.1109/Access.6287639
[25]	VOSSOS V, GARBESI K, SHEN H. Energy savings from direct-DC in US residential buildings[J]. Energy and Buildings, 2014, 68: 223-231. doi: 10.1016/j.enbuild.2013.09.009
[26]	GERBERD L VOSSOSV, FENGW, et al. A simulation-based efficiency comparison of AC and DC power distribution networks in commercial buildings[J]. Applied Energy, 2018, 210: 1167-1187. doi: 10.1016/j.apenergy.2017.05.179
[27]	TOURE S, FASSINOU W F. Technical note cold storage and autonomy in a three compartments photovoltaic solar refrigerator: Experimental and thermodynamic study[J]. Renewable Energy, 1999, 17(4): 587-602. doi: 10.1016/S0960-1481(98)00767-8
[28]	MODI A, CHAUDHURI A, VIJAY B, et al. Performance analysis of a solar photovoltaic operated domestic refrigerator[J]. Applied Energy, 2009, 86(12): 2583-2591. doi: 10.1016/j.apenergy.2009.04.037
[29]	GUPTA B L, BHATNAGAR M, MATHUR J. Optimum sizing of PV panel, battery capacity and insulation thickness for a photovoltaic operated domestic refrigerator[J]. Sustainable Energy Technologies and Assessments, 2014, 7: 55-67. doi: 10.1016/j.seta.2014.03.005
[30]	SPIERS D J, RASINKOSKI A A. Limits to battery lifetime in photovoltaic applications[J]. Solar Energy, 1996, 58(4-6): 147-154. doi: 10.1016/S0038-092X(96)00085-0
[31]	GOTTESFELD P, WERE F H, ADOGAME L, et al. Soil contamination from lead battery manufacturing and recycling in seven African countries[J]. Environmental research, 2018, 161: 609-614. doi: S0013-9351(17)31724-3 pmid: 29248873
[32]	HUANG H J, WANG Z, ZHANG H, et al. An experimental investigation on thermal stratification characteristics with PCMs in solar water tank[J]. Solar Energy, 2019, 177: 8-21. doi: 10.1016/j.solener.2018.11.004
[33]	HANK D, JI J, CAI J Y, et al. Experimental and numerical investigation on a novel photovoltaic direct-driven ice storage air-conditioning system[J]. Renewable Energy, 2021, 172: 514-528. doi: 10.1016/j.renene.2021.03.053
[34]	XU Y F, MA X, HASSANIEN R H E, et al. Performance analysis of static ice refrigeration air conditioning system driven by household distributed photovoltaic energy system[J]. Solar Energy, 2017, 158: 147-160. doi: 10.1016/j.solener.2017.09.002
[35]	LEITE G N P, WESCHENFELDER F, ARAÚJO A M, et al. An economic analysis of the integration between air-conditioning and solar photovoltaic systems[J]. Energy Conversion and Management, 2019, 185: 836-849. doi: 10.1016/j.enconman.2019.02.037
[36]	HAFFAF A, LAKDJA F, ABDESLAM D O, et al. Solar energy for air conditioning of an office building in a case study:Techno-economic feasibility assessment[J]. Renewable Energy Focus, 2021, 39: 148-162. doi: 10.1016/j.ref.2021.09.002
[37]	LI S H, PENG J Q, ZOU B, et al. Zero energy potential of photovoltaic direct-driven air conditioners with considering the load flexibility of air conditioners[J]. Applied Energy, 2021, 304:117821. doi: 10.1016/j.apenergy.2021.117821
[38]	WU H, WANG D J, LIU Y F, et al. Study on the effect of building envelope on cooling load and life-cycle cost in low latitude and hot-humid climate[J]. Procedia Engineering, 2017, 205: 975-982. doi: 10.1016/j.proeng.2017.10.153
[39]	GAO Y H, JI J, HAN K D, et al. Comparative analysis on performance of PV direct-driven refrigeration system under two control methods[J]. International Journal of Refrigeration, 2021, 127: 21-33. doi: 10.1016/j.ijrefrig.2021.03.003
[40]	LI G L, HAN Y H, LI M, et al. Study on matching characteristics of photovoltaic disturbance and refrigeration compressor in solar photovoltaic direct-drive air conditioning system[J]. Renewable Energy, 2021, 172: 1145-1153. doi: 10.1016/j.renene.2021.03.110
[41]	张昕宇, 边萌萌, 李博佳, 等. 建筑太阳能热利用技术研究进展与展望[J]. 建筑科学, 2022, 38(10): 268-274.
	ZHANG Xinyu, BIAN Mengmeng, LI Bojia, et al. Research progress and outlook of solar thermal technology in buildings[J]. Building Science, 2022, 38(10): 268-274.
[42]	PASTUSZAK J, WĘGIEREK P. Photovoltaic cell generations and current research directions for their development[J]. Materials, 2022, 15(16): 5542. doi: 10.3390/ma15165542
[43]	BROWNE M C, NORTON B, MCCORMACK S J. Phase change materials for photovoltaic thermal management[J]. Renewable and Sustainable Energy Reviews, 2015, 47: 762-782. doi: 10.1016/j.rser.2015.03.050
[44]	GHOSH A. Potential of building integrated and attached/applied photovoltaic (BIPV/BAPV) for adaptive less energy-hungry building's skin: A comprehensive review[J]. Journal of Cleaner Production, 2020, 276: 123343. doi: 10.1016/j.jclepro.2020.123343
[45]	MAHMOUDI M, DEHGHAN M, HAGHGOU H, et al. Techno-economic performance of photovoltaic-powered air-conditioning heat pumps with variable-speed and fixed-speed compression systems[J]. Sustainable Energy Technologies and Assessments, 2021, 45: 101113. doi: 10.1016/j.seta.2021.101113
[46]	REZK H, ELTAMALY A M. A comprehensive comparison of different MPPT techniques for photovoltaic systems[J]. Solar Energy, 2015, 112: 1-11. doi: 10.1016/j.solener.2014.11.010
[47]	BARBÓN A, BAYÓN-CUELI C, BAYÓN L, et al. Analysis of the tilt and azimuth angles of photovoltaic systems in non-ideal positions for urban applications[J]. Applied Energy, 2022, 305: 117802. doi: 10.1016/j.apenergy.2021.117802
[48]	KETJOY N, CHAMSA-ARD W, MENSIN P. Analysis of factors affecting efficiency of inverters: Case study grid-connected PV systems in lower northern region of Thailand[J]. Energy Reports, 2021, 7: 3857-3868. doi: 10.1016/j.egyr.2021.06.075
[49]	FARAHMAND M Z, NAZARI M E, SHAMLOU S, et al. The simultaneous impacts of seasonal weather and solar conditions on PV panels electrical characteristics[J]. Energies, 2021, 14(4): 14040845..
[50]	ABIOLA-OGEDENGBE A, HANGAN H, SIDDIQUI K. Experimental investigation of wind effects on a standalone photovoltaic(PV) module[J]. Renewable Energy, 2015, 78: 657-665. doi: 10.1016/j.renene.2015.01.037
[51]	TRZMIEL G, GŁUCHY D, KURZ D. The impact of shading on the exploitation of photovoltaic installations[J]. Renewable Energy, 2020, 153: 480-498. doi: 10.1016/j.renene.2020.02.010
[52]	ZHANG L Y, YI X X, ZHAO M, et al. Reduction in solar photovoltaic generation due to aerosol pollution in megacities in western China during 2014 to 2018[J]. Indoor and Built Environment, 2021, 30(8): 1286-1294. doi: 10.1177/1420326X20939310
[53]	SONG Z, LIU J, YANG H X. Air pollution and soiling implications for solar photovoltaic power generation: A comprehensive review[J]. Applied Energy, 2021, 298: 117247. doi: 10.1016/j.apenergy.2021.117247
[54]	MAGHAMI M R, HIZAM H, GOMES C, et al. Power loss due to soiling on solar panel: A review[J]. Renewable and Sustainable Energy Reviews, 2016, 59: 1307-1316. doi: 10.1016/j.rser.2016.01.044
[55]	AHMAD F F, GHENAI C, HAMID A K, et al. Performance enhancement and infra-red (IR) thermography of solar photovoltaic panel using back cooling from the waste air of building centralized air conditioning system[J]. Case Studies in Thermal Engineering, 2021, 24: 100840. doi: 10.1016/j.csite.2021.100840
[56]	LI H P, ZHANG H F, ZOU B, et al. A generalized study of photovoltaic driven air conditioning potential in cooling season in mainland China[J]. Renewable Energy, 2024, 223: 120048. doi: 10.1016/j.renene.2024.120048
[57]	CHEN L, BAGHOOLIZADEH M, BASEM A, et al. A comprehensive review of a building-integrated photovoltaic system (BIPV)[J]. International Communications in Heat and Mass Transfer, 2024, 159: 108056. doi: 10.1016/j.icheatmasstransfer.2024.108056
[58]	WANG Y P, TIAN W, REN J B, et al. Influence of a building's integrated-photovoltaics on heating and cooling loads[J]. Applied Energy, 2006, 83(9): 989-1003. doi: 10.1016/j.apenergy.2005.10.002
[59]	SÁNCHEZ-PALENCIA P, MARTÍN-CHIVELET N, CHENLO F. Modeling temperature and thermal transmittance of building integrated photovoltaic modules[J]. Solar Energy, 2019, 184: 153-161. doi: 10.1016/j.solener.2019.03.096
[60]	PARK K E, KANG G H, KIM H I, et al. Analysis of thermal and electrical performance of semi-transparent photovoltaic(PV) module[J]. Energy, 2010, 35(6): 2681-2687. doi: 10.1016/j.energy.2009.07.019
[61]	DIDONÉ E L, WAGNER A. Semi-transparent PV windows: A study for office buildings in Brazil[J]. Energy and Buildings, 2013, 67: 136-142. doi: 10.1016/j.enbuild.2013.08.002
[62]	AGATHOKLEOUS R A, KALOGIROU S A. Double skin facades(DSF) and building integrated photovoltaics (BIPV): A review of configurations and heat transfer characteristics[J]. Renewable Energy, 2016, 89: 743-756. doi: 10.1016/j.renene.2015.12.043
[63]	FOSSA M, MÉNÉZO C, LEONARDI E. Experimental natural convection on vertical surfaces for building integrated photovoltaic (BIPV) applications[J]. Experimental Thermal and Fluid Science, 2008, 32(4): 980-990. doi: 10.1016/j.expthermflusci.2007.11.004
[64]	KANCHAN V, TIWARI G N. Performance evaluation of a building integrated semitransparent photovoltaic thermal system for roof and facade[J]. Energy and buildings, 2012, 45: 211-2183. doi: 10.1016/j.enbuild.2011.11.008
[65]	陈江恩, 孙杰, 冯博, 等. 光伏建筑一体化项目不同安装方式的案例分析[J]. 建筑节能, 2014, 42(4):35-38,67.
	CHEN Jiang'en, SUN Jie, FENG Bo, et al. Case analysis on various installation methods of building integrated photovoltaic[J]. Building Energy Efficiency, 2014, 42(4): 35-38, 67.
[66]	CARR A J, PRYOR T L. A comparison of the performance of different PV module types in temperate climates[J]. Solar energy, 2004, 76(1/3): 285-294. doi: 10.1016/j.solener.2003.07.026
[67]	SHAHRESTANI M, YAO R, ESSAH E, et al. Experimental and numerical studies to assess the energy performance of naturally ventilated PV facade systems[J]. Solar Energy, 2017, 147: 37-51. doi: 10.1016/j.solener.2017.02.034
[68]	KAISER A S, ZAMORA B, MAZÓN R, et al. Experimental study of cooling BIPV modules by forced convection in the air channel[J]. Applied Energy, 2014, 135: 88-97. doi: 10.1016/j.apenergy.2014.08.079
[69]	AGATHOKLEOUS R A, KALOGIROU S A. Part I: Thermal analysis of naturally ventilated BIPV system: Experimental investigation and convective heat transfer coefficients estimation[J]. Solar Energy, 2018, 169: 673-681. doi: 10.1016/j.solener.2018.02.048
[70]	SUN C, LU Y F, JU X L. Experimental and numerical study to optimize building integrated photovoltaic (BIPV) roof structure[J]. Energy and Buildings, 2024, 309: 114070. doi: 10.1016/j.enbuild.2024.114070
[71]	ELSAYED M S. Optimizing thermal performance of building-integrated photovoltaics for upgrading informal urbanization[J]. Energy and Buildings, 2016, 116: 232-248. doi: 10.1016/j.enbuild.2016.01.004
[72]	PENG J Q, LU L, YANG H X, et al. Investigation on the annual thermal performance of a photovoltaic wall mounted on a multi-layer facade[J]. Applied Energy, 2013, 112: 646-656. doi: 10.1016/j.apenergy.2012.12.026
[73]	何伟, 张永煦, 刘俊跃, 等. 空冷型光伏双层窗在华东地区的热性能模拟分析[J]. 太阳能学报, 2009, 30(11): 1476-1480.
	HE Wei, ZHANG Yongxu, LIU Junyue, et al. Thermal performance evaluation of air cooling photovoltaic double-glass window in East China[J]. Acta Energiae Solaris Sinica, 2009, 30(11): 1476-1480.
[74]	PENG J Q, CURCIJA D C, LU L, et al. Numerical investigation of the energy saving potential of a semi-transparent photovoltaic double-skin facade in a cool-summer Mediterranean climate[J]. Applied Energy, 2016, 165: 345-356. doi: 10.1016/j.apenergy.2015.12.074
[75]	何伟, 季杰. 光伏光热建筑一体化对建筑节能影响的理论研究[J]. 暖通空调, 2003, 33(6): 8-11.
	HE Wei, JI Jie. Theoretical study of photovoltaic/thermal integrated buildings on energy efficiency[J]. Journal of HV & AC, 2003, 33(6): 8-11.
[76]	FUNG T Y Y, YANG H. Study on thermal performance of semi-transparent building-integrated photovoltaic glazings[J]. Energy and Buildings, 2008, 40(3): 341-350. doi: 10.1016/j.enbuild.2007.03.002
[77]	裴刚, 周天泰, 季杰, 等. 两种新型太阳能通风窗在香港地区的实验研究[J]. 太阳能学报, 2009, 30(3): 282-286.
	PEI Gang, ZHOU Tiantai, JI Jie, et al. Experimental study of two novel ventilated solar screen windows in Hong Kon[J]. Acta Energiae Solaris Sinica, 2009, 30(3): 282-286.
[78]	YOO S H, MANZ H. Available remodeling simulation for a BIPV as a shading device[J]. Solar Energy Materials and Solar Cells, 2011, 95(1): 394-397.
[79]	王喜良. 光伏热电热回收新风系统的实验研究[D]. 长沙: 湖南大学, 2018.
	WANG Xiliang. The performance research of the photovoltaic thermoelectric heat recovery fresh air ventilaton[D]. Changsha: Hunan University, 2018.
[80]	HU Z T, HE W, HU D Y, et al. Design, construction and performance testing of a PV blind-integrated Trombe wall module[J]. Applied Energy, 2017, 203: 643-656. doi: 10.1016/j.apenergy.2017.06.078
[81]	ATHIENITIS A K, BARONE G, BUONOMANO A, et al. Assessing active and passive effects of facade building integrated photovoltaics/thermal systems: Dynamic modelling and simulation[J]. Applied Energy, 2018, 209: 355-382. doi: 10.1016/j.apenergy.2017.09.039

模式	说明
仅光伏供电	当光伏发电量恰好与空调系统能耗相等时，将光伏系统产生的电量提供给空调系统使用
光伏发电盈余	当光伏发电量高于空调系统能耗时，光伏系统发出的电量除向空调系统供电外，其余全部并入公共电网
公共电网补充	在阴雨天或光伏系统发生故障时，若光伏发电不能满足空调系统的能耗需求，光伏系统与公共电网同时为空调系统供电
