面向“双碳”目标的碳电市场融合交易探讨

doi:10.3969/j.issn.1674-1951.2021.06.004

华电技术 ›› 2021, Vol. 43 ›› Issue (6): 33-40.doi: 10.3969/j.issn.1674-1951.2021.06.004

面向“双碳”目标的碳电市场融合交易探讨

吉斌¹^,²(), 孙绘¹^,²^,^*(), 梁肖³, 刘妍⁴, 李凡⁴

1.南瑞集团有限公司（国网电力科学研究院有限公司）,南京 211106
2.国电南瑞科技股份有限公司,南京 211106
3.国网安徽省电力调度中心,合肥 230000
4.国网渭南供电公司,陕西渭南 714000

收稿日期:2021-04-26 修回日期:2021-05-17 出版日期:2021-06-25 发布日期:2021-06-25
通讯作者: 孙绘
作者简介:吉斌（1992—）,男,安徽当涂人,工程师,工学硕士,从事电力市场、电力自动化调度以及区块链应用融合技术方面的研究（E-mail： 1498206259@qq.com）。
基金资助:
国家电网有限公司科技项目(SCTYHT/16-JS-198)

Discussion on convergent trading of the carbon and electricity market on the path to carbon peak and carbon neutrality

JI Bin¹^,²(), SUN Hui¹^,²^,^*(), LIANG Xiao³, LIU Yan⁴, LI Fan⁴

1. NARI Group Corporation（State Grid Electric Power Research Institute Company Limited）,Nanjing 211106,China
2. NARI Technology Company Limited,Nanjing 211106,China
3. State Grid Anhui Electric Power Dispatching Center,Hefei 230000,China
4. State Grid Weinan Electric Power Supply Company,Weinan 714000,China

Received:2021-04-26 Revised:2021-05-17 Online:2021-06-25 Published:2021-06-25
Contact: SUN Hui

摘要/Abstract

摘要：

实现“双碳”目标,提高新能源接入和消纳比例,可通过碳电市场耦合运行,促进节能减排。首先从电力市场角度出发,以节能减排为目标,分析电力市场与碳权市场的关系,探讨了碳电市场关联方式;其次根据电力市场原则和碳权核发与配额的市场机制,设计了碳电联合运行流程和模式,根据市场运行模式开展碳电联合运行的市场机制设计;最后根据设计的碳电运行模式、市场机制,开展量化的碳电市场机制验证。通过算例分析可以看出,设计的市场机制通过引导负荷侧市场主体从碳电市场响应不平衡电量,获得碳权并参与碳权市场而获得收益,从而降低火电市场主体的“热备用”容量,降低CO₂的排放,促进“双碳”目标的实现。

关键词: 电力交易, 碳权交易, 碳电耦合, 机制设计, 市场融合, “双碳”目标, 碳中和, 碳达峰

Abstract:

To achieve the goal of "carbon peak and carbon neutrality" and increase the access and consumption proportion of new energy,carbon market and power market are coupled to simulate energy conservation and emission reduction.From the perspective of electricity market,the relationship between electricity market and carbon emission right market and their coupling method are analyzed to meet the target of energy conservation and emission reduction.Then,according to the principles of electricity market and the allocating and issuing mechanism of carbon emission rights,a joint operation mode for carbon and power market is designed.And the correspondent market mechanism for the joint operation of carbon and electricity market is developed.Finally,according to the designed operation mode and market mechanism,a quantitative verification for carbon and electricity market is carried out.It can be seen from the examples that the market mechanism guides the load-side market entities to respond to the unbalanced electricity from electricity and carbon market,profiting from earning carbon emission rights and participating in carbon emission rights market.Thereby,the mechanism can reduce the thermal reserve capacity of power system which is dominated by thermal power units,restrict CO₂ emissions,and promote the realization of the "carbon peak and carbon neutrality".

Key words: electricity transaction, carbon emission rights transaction, carbon and electricity coupling, mechanism design, market integration, carbon peak and carbon neutrality, carbon neutrality, carbon peak

中图分类号:

TM732：TK01 ⁺8

吉斌, 孙绘, 梁肖, 刘妍, 李凡. 面向“双碳”目标的碳电市场融合交易探讨[J]. 华电技术, 2021, 43(6): 33-40.

JI Bin, SUN Hui, LIANG Xiao, LIU Yan, LI Fan. Discussion on convergent trading of the carbon and electricity market on the path to carbon peak and carbon neutrality[J]. Huadian Technology, 2021, 43(6): 33-40.

图/表 9

图1

图2

图3

表1

表2

图4

图5

图6

图7

参考文献 19

[1]	何建坤. 《巴黎协定》新机制及其影响[J]. 世界环境, 2016(1):16-18.
	HE Jiankun. New mechanism and influence of “Paris Agreement”[J]. World Environment, 2016(1):16-18.
[2]	邹骥, 黄婷婷. 履行《巴黎协定》要保持战略定力[N]. 中国环境报, 2017-06-12(3).
[3]	吉斌, 昌力, 陈振寰, 等. 基于区块链技术的电力碳排放权交易应用与市场机制设计[J/OL]. 电力系统自动化:1-15 [2021-05-17]. http://kns.cnki.net/kcms/detail/32.1180.TP.20210209.1701.010.html.
	JI Bin, CHANG Li, CHEN Zhenhuan, et al. Blockchain technology based design and application of market mechanism for power carbon emission allowance trading[J/OL]. Automation of Electric Power Systems:1-15 [2021-05-17]. http://kns.cnki.net/kcms/detail/32.1180.TP.20210209.1701.010.html.
[4]	ZHENG Y, ZHOU M, WEN F H. Asymmetric effects of oil shocks on carbon allowance price:Evidence from China[J]. Energy Economics, 2021,97.DOI: 10.1016/j.eneco.2021.105183.
[5]	LIU B L, SUN Z Q, LI H H. Can carbon trading policies promote regional green innovation efficiency?Empirical data from pilot regions in China[J]. Sustainability, 2021,13(5):2891. doi: 10.3390/su13052891
[6]	LUO W, ZHANG Y R, GAO Y L, et al. Life cycle carbon cost of buildings under carbon trading and carbon tax system in China[J]. Sustainable Cities and Society, 2021,66.DOI: 10.1016/j.scs.2020.102509.
[7]	刘逸飞. 我国碳排放权市场影响因素分析——以广州碳排放权交易所为例[J]. 中国林业经济, 2021(1):79-82.
	LIU Yifei. Analysis on the influencing factors of China's carbon emissions market——Taking Guangzhou carbon emissions exchange as an example[J]. China Forestry Economics, 2021(1):79-82.
[8]	MEMARI Y, MEMARI A, EBRAHIMNEJAD S, et al. A mathematical model for optimizing a biofuel supply chain with outsourcing decisions under the carbon trading mechanism[J]. Biomass Conversion and Biorefinery, 2021.DOI: 10.1007/s13399-020-01264-1.
[9]	陈启鑫, 房曦晨, 郭鸿业, 等. 电力现货市场建设进展与关键问题[J]. 电力系统自动化, 2021,45(6):3-15.
	CHEN Qixin, FANG Xichen, GUO Hongye, et al. The progress and key issues of electric power spot market construction[J]. Automation of Electric Power Systems, 2021,45(6):3-15.
[10]	朱峰, 刘力涵. 电力现货市场首批试点地区建设情况分析[J]. 电力需求侧管理, 2021,23(2):74-78,94.
	ZHU Feng, LIU Lihan. Analysis of the construction of the first batch of pilot areas in the power spot market[J]. Power Demand Side Management, 2021,23(2):74-78,94.
[11]	吉斌, 谭建成. 利用区块链技术的配电侧分布式微电能交易初探[J]. 现代电力, 2019,36(1):29-36.
	JI Bin, TAN Jiancheng. A preliminary study on distributed micro-electricity transactions on the distribution side using blockchain technology[J]. Modern Electric Power, 2019,36(1):29-36.
[12]	吉斌. 基于区块链技术的产消用户电力零售交易机制与模式研究[D]. 南宁:广西大学, 2019.
[13]	吉斌, 刘妍, 朱丽叶, 等. 基于联盟区块链的电力碳权交易机制设计[J]. 华电技术, 2020,42(8):32-40.
	JI Bin, LIU Yan, ZHU Liye, et al. Design of carbon emission permit trading mechanism in power industry based on consortium blockchain[J]. Huadian Technology, 2020,42(8):32-40.
[14]	吉斌, 莫峻, 谭建成. 高比例光伏电能产消群电力需求响应机制设计[J]. 电网技术, 2018,42(10):3315-3323.
	JI Bin, MO Jun, TAN Jiancheng. Design of power demand response mechanism for high proportion of photovoltaic prosumer[J]. Power System Technology, 2018,42(10):3315-3323.
[15]	王胜寒, 郭创新, 冯斌, 等. 区块链技术在电力系统中的应用:前景与思路[J]. 电力系统自动化, 2020,44(11):10-24.
	WANG Shenghan, GUO Chuangxin, FENG Bin, et al. Application of blockchain technology in power systems:Prospects and ideas[J]. Automation of Electric Power System, 2020,44(11):10-24.
[16]	崔树银, 陆奕, 常啸. 考虑信用评分机制的电力碳排放交易区块链模型[J]. 电力建设, 2019,40(1):104-111.
	CUI Shuyin, LU Yi, CHANG Xiao. Research on model of blockchain-enabled power carbon emission trade considering credit scoring mechanism[J]. Electric Power Construction, 2019,40(1):104-111.
[17]	曾诗钦, 霍如, 黄韬, 等. 区块链技术研究综述:原理、进展与应用[J]. 通信学报, 2020,41(1):134-151.
	ZENG Shiqin, HUO Ru, HUANG Tao, et al. Survey of blockchain:Principle,progress and application[J]. Journal on Communications, 2020,41(1):134-151. doi: 10.1111/j.1460-2466.1991.tb02297.x
[18]	碳排放为什么应该是200-300元每吨?[EB/OL].(2017-05-26)[2021-05-15]. http://www.tanpaifang.com/tanguwen/2017/0526/59500.html.
[19]	杜娟. 广东2019年碳排放配额4.65亿吨电力企业的免费配额比例为95%[EB/OL]. (2019-11-04)[2021-05-15]. http://news.bjx.com.cn/html/20191104/1018158.shtml.

序号	市场主体	响应电量/（kW·h）	申报价格/(元·kg^-1)
1	f₁	0.125	0.396
2	f₂	0.213	0.389
3	f₃	0.330	0.390
4	f₄	0.101	0.389
5	f₅	0.090	0.399
6	f₆	0.180	0.401
7	f₇	0.241	0.397
8	f₈	0.030	0.394
9	f₉	0.510	0.389
10	f₁₀	0.020	0.388
11	f₁₁	-0.160	—
12	f₁₂	0.345	0.421
13	f₁₃	0.110	0.419
14	f₁₄	-0.140	—
15	f₁₅	-0.200	—
16	f₁₆	0.280	0.409
17	f₁₇	0.223	0.385
18	f₁₈	0.179	0.394
19	f₁₉	0.030	0.387
20	f₂₀	0.113	0.379

序号	市场主体	碳权核发量/kg	碳权交易申报价格/(元·kg^-1)
1	f₁	100.0	0.249
2	f₂	170.4	0.249
3	f₃	264.0	0.251
4	f₄	80.8	0.255
5	f₅	72.0	0.255
6	f₆	144.0	0.251
7	f₇	192.8	0.259
8	f₈	24.0	0.260
9	f₉	408.0	0.257
10	f₁₀	16.0	0.256
11	f₁₁	—	—
12	f₁₂	276.0	0.259
13	f₁₃	88.0	0.256
14	f₁₄	—	—
15	f₁₅	—	—
16	f₁₆	224.0	0.257
17	f₁₇	178.4	0.258
18	f₁₈	143.2	0.254
19	f₁₉	24.0	0.252
20	f₂₀	90.4	0.253
