含光热电站的风光联合发电系统互补效益评估

doi:10.3969/j.issn.2097-0706.2023.02.001

综合智慧能源 ›› 2023, Vol. 45 ›› Issue (2): 1-9.doi: 10.3969/j.issn.2097-0706.2023.02.001

• 源源互补 • 下一篇

含光热电站的风光联合发电系统互补效益评估

马志程¹(), 李维俊²(), 周强¹, 王定美¹, 吕清泉¹, 董海鹰²^,^*()

1.国网甘肃省电力公司电力科学研究院，兰州 730070
2.兰州交通大学新能源与动力工程学院，兰州 730070

收稿日期:2022-07-06 修回日期:2022-08-04 出版日期:2023-02-25
通讯作者: *董海鹰（1966），男，教授，博士生导师，博士，从事电力系统运行与优化控制、新能源发电等方面的研究，hydong@mail.lzjtu.cn。
作者简介:马志程（1969），男，高级工程师，硕士，从事电力系统、信息通信技术等方面的研究，mazc@gs.sgcc.com.cn；
李维俊（1997），女，在读硕士研究生，从事电力系统和综合能源系统研究，lwjdyx0105@163.com。
基金资助:
甘肃省科技重大专项计划项目(19ZD2GA003);国网甘肃省电力公司科技项目(SGGSKY00WYJS2100243)

Evaluation on the complementary benefit of a wind-solar combined power generation system with a photothermal power station

MA Zhicheng¹(), LI Weijun²(), ZHOU Qiang¹, WANG Dingmei¹, LYU Qingquan¹, DONG Haiying²^,^*()

1. Electric Power Research Institute of State Grid Gansu Electric Power Company，Lanzhou 730070，China
2. School of New Energy and Power Engineering，Lanzhou Jiaotong University，Lanzhou 730070，China

Received:2022-07-06 Revised:2022-08-04 Published:2023-02-25
Supported by:
Major Projects of Science and Technology in Gansu Province(19ZD2GA003);Science and Technology Project of State Grid Gansu Electric Power Company(SGGSKY00WYJS2100243)

摘要/Abstract

摘要：

针对包含新能源的多能互补发电系统难以合理量化互补效益的问题，提出了一种基于蒙特卡洛与可信容量的含光热电站的风光联合发电系统互补效益评估方法。基于序贯蒙特卡洛建立含光热电站的风光联合输出概率模型，实现风电、光伏、光热机组的随机生产模拟，对该联合发电系统的可信容量进行计算并建立互补效益评估指标；然后通过计算不同光热、风光装机配比下的互补效益指标实现含光热电站的风光联合发电系统互补效益的评估；最后采用IEEE-RTS来验证，结果表明，该方法可有效评估含光热电站的风光联合系统的互补效益。

关键词: 新能源, 风光联合发电系统, 光热电站, 可信容量, 序贯蒙特卡洛, 互补效益

Abstract:

Since the complementary benefit of a multi-energy complementary power generation system integrating new energies can hardly be quantified，a complementary benefit evaluation method for a wind-solar combined power generation system with a photothermal power station based on Monte Carlo and credible capacity is proposed. The method sets up the output model of the complementary system based on sequential Monte Carlo，realizing the probabilistic production simulations for the wind turbines，solar panels and photothermal units. According to the calculated credible capacity of the combined power generation system， the evaluation indicators for the system are obtained. By comparing the complementary benefits of a wind-solar-photothermal combined power generation system under different proportions of installed wind turbines and photothermal units， the complementary benefit evaluation for the system is completed. Finally， the evaluation method is verified by IEEE-RTS.The results show that this method can effectively evaluate the complementary benefit of the wind-solar combined power generation system with a photothermal power station.

Key words: new energy, wind-solar combined power generation system, photothermal power station, credible capacity, sequential Monte Carlo, complementary benefit evaluation

中图分类号:

TK019：TM615

马志程, 李维俊, 周强, 王定美, 吕清泉, 董海鹰. 含光热电站的风光联合发电系统互补效益评估[J]. 综合智慧能源, 2023, 45(2): 1-9.

MA Zhicheng, LI Weijun, ZHOU Qiang, WANG Dingmei, LYU Qingquan, DONG Haiying. Evaluation on the complementary benefit of a wind-solar combined power generation system with a photothermal power station[J]. Integrated Intelligent Energy, 2023, 45(2): 1-9.

图/表 8

图1

表1

图2

图3

图4

图5

图6

图7

参考文献 35

[1]	吴慧军, 申建建, 程春田, 等. 网省两级调度多电源短期联合调峰方法[J]. 中国电机工程学报, 2015, 35(11):2743-2755.
	WU Huijun, SHEN Jianjian, CHENG Chuntian, et al. Coordination method of regional and provincial grids for short-term peak shaving operation among hybrid energy sources[J]. Proceedings of the CSEE, 2015, 35(11):2743-2755.
[2]	姚良忠, 朱凌志, 周明. 高比例可再生能源电力系统的协同优化运行技术展望[J]. 电力系统自动化, 2017, 41(9):36-43.
	YAO Liangzhong, ZHU Lingzhi, ZHOU Ming. Prospects of coordination and optimization for power systems with high proportion of renewable energy[J]. Automation of Electric Power Systems, 2017, 41 (9): 36-43.
[3]	杜尔顺, 张宁, 康重庆, 等. 太阳能光热发电并网运行及优化规划研究综述与展望[J]. 中国电机工程学报, 2016(21):5765-5775.
	DU Ershun, ZHANG Ning, KANG Chongqing, et al. Reviews and prospects of the operation and planning optimization for grid integrated concentrating solar power[J]. Proceedings of the CSEE, 2016 (21): 5765-5775.
[4]	王志峰, 何雅玲, 康重庆, 等. 明确太阳能热发电战略定位促进技术发展[J]. 华电技术, 2021, 43(11): 1-4.
	WANG Zhifeng, HE Yaling, KANG Chongqing, et al. Strategic positioning of solar thermal power generation to promote technological progress[J]. Huadian Technology, 2021, 43(11): 1-4.
[5]	LIU H, CHAU K T, ZHANG X. An efficient wind-photovoltaic hybrid generation system using doubly excited permanent-magnet brushless machine[J]. IEEE Transactions on Industrial Electronics, 2010, 57(3):831-839. doi: 10.1109/TIE.2009.2022511
[6]	XU T, ZHANG N. Coordinated operation of concentrated solar power and wind resources for the provision of energy and reserve services[J]. IEEE Transactions on Power System, 2017, 32(2): 1260-1271.
[7]	潘丽, 杜尔顺, 王剑晓, 等. 风力发电与光热发电联合运行经济效益研究[J]. 综合智慧能源, 2022, 44(1):26-30. doi: 10.3969/j.issn.2097-0706.2022.01.004
	PAN Li, DU Ershun, WANG Jianxiao, et al. Research on economic benefits of joint operation of wind farms and concentrating solar power plants[J]. Integrated Intelligent Energy, 2022, 44(1): 26-30. doi: 10.3969/j.issn.2097-0706.2022.01.004
[8]	崔杨, 杨志文, 张节潭, 等. 计及综合成本的风电-光伏-光热联合出力调度策略[J]. 高电压技术, 2019, 45(1):269-275.
	CUI Yang, YANG Zhiwen, ZHANG Jietan, et al. Scheduling strategy of wind power-photovoltaic power-concentrating solar power considering comprehensive costs[J]. High Voltage Engineering, 2019, 45 (1): 269-275.
[9]	张宏, 陈钊, 黄蓉, 等. 风电-光伏-光热联合发电系统的模糊多目标优化模型[J]. 电源学报, 2019, 14(6):1-13.
	ZHANG Hong, CHEN Zhao, HUANG Rong, et al. Fuzzy multi-objective optimization model of wind-PV-CSP hybrid power generation system[J]. Journal of Power Supply, 2019, 14 (6): 1-13.
[10]	杨宏基, 周明, 武昭原, 等. 含光热电站的电-热能源系统优化运行机制[J]. 电网技术, 2021, 46(1):175-184.
	YANG Hongji, ZHOU Ming, WU Zhaoyuan, et al. Optimal operation of electro-thermal energy systems with concentrated solar power plant[J]. Power System Technology, 2021, 46(1):175-184.
[11]	傅旭, 王进军, 张雨津, 等. 含多类型电源的电力系统光热发电效益评估方法[J]. 电力工程技术, 2022, 41(1):213-218.
	FU Xu, WANG Jinjun, ZHANG Yujin, et al. Benefit evaluation method of solar thermal power generation in power system with multiple types of power sources[J]. Power Engineering Technology, 2022, 41 (1): 213-218.
[12]	曾鸣, 刘英新, 周鹏程, 等. 综合能源系统建模及效益评价体系综述与展望[J]. 电网技术, 2018, 42(6):1697-1708.
	ZENG Ming, LIU Yingxin, ZHOU Pengcheng, et al. Review and prospects of integrated energy system modeling and benefit evaluation[J]. Power System Technology, 2018, 42 (6): 1697-1708.
[13]	DU E, ZHANG N, HODGE B M, et al. Economic justification of concentrating solar power in high renewable energy penetrated power systems[J]. Applied Energy, 2018, 222: 649-661. doi: 10.1016/j.apenergy.2018.03.161
[14]	FANG L, DONG H Y, DING K, et al. Peak shaving strategy of power grid with concentrating solar power plant[C]// IEEE International Conference on Automation Science and Engineering. IEEE, 2017: 1633-1638.
[15]	XU T, ZHANG N. Coordinated operation of concentrated solar power and wind resources for the provision of energy and reserve services[J]. IEEE Transactions on Power System, 2016, 32(2): 1260-1271.
[16]	BAKOS G C, TSAGAS N F. Technoeconomic assessment of a hybrid solar /wind installation for electrical energy saving[J]. Energy and Buildings, 2003, 35(2):139-145. doi: 10.1016/S0378-7788(02)00023-3
[17]	夏翔, 方建亮, 谢颖捷, 等. 基于层次分析与灰色模糊综合评价的多能互补工程项目综合效益评估[J]. 济南大学学报(自然科学版), 2020, 34(1):76-84.
	XIA Xiang, FANG Jianliang, XIE Yingjie, et al. Comprehensive benefit evaluation of multi-energy complementary engineering project based on analytic hierarchy process and grey fuzzy comprehensive evaluation[J]. Journal of Jinan University(Natural Science Edition), 2020, 34 (1): 76-84.
[18]	赵鑫, 郑文禹, 侯智华, 等. 基于粒子群优化算法的多能互补系统经济调度研究[J]. 华电技术, 2021, 43(4): 14-20.
	ZHAO Xin, ZHENG Wenyu, HOU Zhihua, et al. Research on economic dispatch of multi-energy complementary system based on Particle Swarm Optimization[J]. Huadian Technology, 2021, 43(4): 14-20.
[19]	辛禾. 考虑多能互补的清洁能源协同优化调度及效益均衡研究[D]. 北京: 华北电力大学, 2019.
	XIN He. Research on collaborative optimal dispatch and benefit balance of clean energy considering multi-energy complementarity[D]. Beijing: North China Electric Power University, 2019.
[20]	李轩, 张家安, 吴林林, 等. 可再生能源汇集地区风电与光伏发电的综合容量可信度评估[J]. 太阳能学报, 2017, 38(3):707-714.
	LI Xuan, ZHANG Jia'an, WU Linlin, et al. Comprehensive capacity credit evaluation of wind and photovoltaic power in dense renewable energy areas[J]. Acta Energiae Solaris Sinica, 2017, 38 (3): 707-714.
[21]	WANG J, ZHAO H, WANG Z, et al. An assessment method of substation credible capacity of microgrids considering the high voltage connection mode[C]// IOP Conference Series: Materials Science and Engineering. IOP Publishing, 2018, 452(3): 032077.
[22]	吴鸣, 季宇, 郑楠, 等. 基于序列运算的风光储混合微电网可信容量评估[J]. 太阳能学报, 2021, 42(3):251-258.
	WU Ming, JI Yu, ZHENG Nan, et al. Assessment on credible capacity of hybrid microgrid containing wind/photovoltaic/storage based on sequence operation[J]. Acta Energiae Solaris Sinica, 2021, 42 (3): 251-258.
[23]	ZHU S, ZHANG Y, CHOWDHURY A A. Capacity credit of wind generation based on minimum resource adequacy procurement[J]. IEEE Transactions on Industry Applications, 2012, 48(2):730-735. doi: 10.1109/TIA.2011.2180287
[24]	叶茂, 刘艳, 顾雪平, 等. 基于动态风电穿透功率极限的黑启动方案制定[J]. 中国电机工程学报, 2018, 38(3):744-752.
	YE Mao, LIU Yan, GU Xueping, et al. Black start scheme formation considering dynamic wind power penetration limit[J]. Proceedings of the CSEE, 2018, 38(3): 744-752.
[25]	赵争鸣, 刘建政, 孙晓瑛, 等. 太阳能光伏发电及其应用[M]. 北京: 科学出版社, 2005:43-57.
[26]	LASLETT D, CREAGH C, JENNINGS P. A method for generating synthetic hourly solar radiation data for any location in the south west of Western Australia, in a world wide web page[J]. Renewable Energy, 2014, 68:87-102. doi: 10.1016/j.renene.2014.01.015
[27]	HOLLANDS K G T, HUGET R G. A probability density function for the clearness index with applications[J]. Solar Energy, 1983, 30(3):195-209. doi: 10.1016/0038-092X(83)90149-4
[28]	LIRA I. Assigning a probability density function for the value of a quantity based on discrete data: The resolution problem[J]. Metrologia, 2012, 49(6):765. doi: 10.1088/0026-1394/49/6/765
[29]	史昭娣, 王伟胜, 黄越辉, 等. 考虑决策相关随机规划的光热电站容量配置[J]. 中国电机工程学报, 2020, 40(23):7511-7522.
	SHI Zhaodi, WANG Weisheng, HUANG Yuehui, et al. Capacity optimization of concentrating solar power plant based on decision-dependent stochastic programming[J]. Proceedings of the CSEE, 2020, 40 (23): 7511-7522.
[30]	曹传胜. 塔式太阳能热发电站性能的影响因素研究[J]. 太阳能学报, 2020, 41(10):223-228.
	CAO Chuansheng. Investigation of influence factors on performance of solar tower power station[J]. Acta Energiae Solaris Sinica, 2020, 41(10):223-228.
[31]	张远巍, 郭枭, 汪凌飞, 等. 新型太阳能光伏光热一体化系统性能实验研究[J]. 可再生能源, 2018, 36(10):1449-1454.
	ZHANG Yuanwei, GUO Xiao, WANG Lingfei, et al. Experimental study of a new solar hybrid photovoltaic-thermal modules[J]. Renewable Energy Resources, 2018, 36 (10): 1449-1454.
[32]	崔杨, 杨志文, 仲悟之, 等. 基于成本最优的含储热光热电站与火电机组联合出力日前调度[J]. 电力自动化设备, 2019, 39(2):71-77.
	CUI Yang, YANG Zhiwen, ZHONG Wuzhi, et al. Day-ahead dispatch for output of combined CSP with thermal storage system and thermal power units based on minimized operation cost[J]. Electric Power Automation Equipment, 2019, 39 (2): 71-77.
[33]	段偲默, 苗世洪, 霍雪松, 等. 基于动态Copula的风光联合出力建模及动态相关性分析[J]. 电力系统保护与控制, 2019, 47(5): 35-42.
	DUAN Simo, MIAO Shihong, HUO Xuesong, et al. Modeling and dynamic correlation analysis of wind/solar power joint output based on dynamic Copula[J]. Power System Protection and Control, 2019, 47 (5): 35-42.
[34]	何俊, 邓长虹, 徐秋实, 等. 基于等可信容量的风光储电源优化配置方法[J]. 电网技术, 2013, 37(12):3317-3324.
	HE Jun, DENG Changhong, XU Qiushi, et al. Optimal configuration of distributed generation system containing wind PV battery power sources based on equivalent credible capacity theory[J]. Power System Technology, 2013, 37 (12): 3317-3324.
[35]	WONG P, ALBRECHT P, BILLINTON R, et al. A report prepared by the reliability test system task force of the application of probability methods subcommittee[J]. IEEE Transactions on Power Apparatus and Systems, 1999, 98(6): 2047-2054.

参数			数值
风电机组	额定容量/MW		2
	风速/（m·s^-1）	切入	2.5
		切出	18.0
		额定	12.0
光伏机组	电池面积/m²		2
	最大输出功率/W		280
	转换效率/%		14.4
