基于随机模型预测控制的智能楼宇能量管理方法

doi:10.3969/j.issn.2097-0706.2022.10.011

摘要/Abstract

摘要：

建筑楼宇不仅是我国的能耗大户，更是碳排放的重要来源。智慧建筑能耗管理对于提高建筑楼宇系统能量利用效率、实现节能降碳至关重要，然而由于环境温度、辐照度等环境因素预测的不确定性，对系统经济运行造成不可忽略的影响。提出了一种考虑建筑蓄热特性，基于机会约束随机模型预测控制的智能楼宇能量管理方法。该方法通过将建筑热动态特性引入楼宇能量系统模型，考虑了由于室外温度和光照强度预测偏差导致状态约束违背的概率描述，通过机会约束与仿射扰动反馈结合，将概率约束转化为确定性约束，提出基于机会约束随机模型预测控制的楼宇能量管理优化问题，实现各用能设备的优化调度。仿真结果表明，该方法能够有效减少环境因素预测不确定性引起运行成本的增加，提升用户舒适度及系统整体运行的鲁棒性。

关键词: 智能楼宇, 暖通空调系统, 随机模型预测控制, 优化调度, 热舒适度, 碳排放, 地源热泵

Abstract:

Buildings are major energy consumers and carbon emission sources in China.Building energy management systems are vital to improve the energy utilization efficiency，save energy consumption and reduce carbon emissions.However，the prediction uncertainties of ambient temperature，solar irradiation and other environmental factors are detrimental to the economy of the whole system.Accordingly，a smart building energy management method based on chance-constrained stochastic model predictive control considering the characteristics of buildings'heat storage is proposed.By introducing the building thermal dynamic characteristics into the building energy system model，the proposed method descripts the probability of the state constraint violation caused by the prediction deviation of outdoor temperature and solar irradiation.Combining the chance constraint and affine disturbance feedback，the probability constraint can be transformed into deterministic constraint.Then，a smart building energy management model based on chance-constrained stochastic model predictive control is constructed，to realize the optimal operation of each energy-consuming equipment.The simulation results have shown that the proposed method can effectively reduce the operating costs caused by the uncertainty prediction on environmental factors and improve the comfortableness and robustness of the overall system.

Key words: smart building, HVAC system, stochastic model predictive control, optimal scheduling, thermal comfort, carbon emissions, geothermal heat pump

中图分类号:

TK02

张怡, 房方. 基于随机模型预测控制的智能楼宇能量管理方法[J]. 综合智慧能源, 2022, 44(10): 83-90.

ZHANG Yi, FANG Fang. Smart building energy management strategy based on stochastic model predictive control[J]. Integrated Intelligent Energy, 2022, 44(10): 83-90.

图/表 10

图1

图2

图3

图4

图5

图6

图7

表1

表2

图8

参考文献 22

[1]	中国建筑节能协会能耗专委会. 中国建筑能耗研究报告(2020)成果发布[Z]. 2020.
[2]	张爱平, 赵利兴, 刘静. 楼宇型综合能源服务系统智能优化运行研究[J]. 综合智慧能源, 2022, 44(2):42-48. doi: 10.3969/j.issn.2097-0706.2022.02.007
	ZHANG Aiping, ZHAO Lixing, LIU Jing. Research on optimized operation of building-type integrated energy service systems[J]. Integrated Intelligent Energy, 2022, 44(2):42-48. doi: 10.3969/j.issn.2097-0706.2022.02.007
[3]	HU M, XIAO F, JORGENSEN J B, et al. Price-responsive model predictive control of floor heating systems for demand response using building thermal mass[J]. Applied Thermal Engineering, 2019, 153:316-329. doi: 10.1016/j.applthermaleng.2019.02.107
[4]	陈厚合, 李泽宁, 姜涛, 等. 基于模型预测控制的智能楼宇用能灵活性调控策略[J]. 电力系统自动化, 2019, 43(16):116-124.
	CHEN Houhe, LI Zening, JIANG Tao, et al. Flexible energy scheduling strategy in smart buildings based on model predictive control[J]. Automation of Electric Power Systems, 2019, 43(16):116-124.
[5]	AFRAM A, JANABI F. Gray-box modeling and validation of residential HVAC system for control system design[J]. Applied Energy, 2015, 137:134-150. doi: 10.1016/j.apenergy.2014.10.026
[6]	FINCK C, LI R, ZEILER W. Identification of a dynamic system model for a building and heating system including heat pump and thermal energy storage[J]. MethodsX, 2020, 7:100866. doi: 10.1016/j.mex.2020.100866
[7]	SEAL S, BOULET B, DEHKORDI V. Centralized model predictive control strategy for thermal comfort and residential energy management[J]. Energy, 2020, 212: 118456. doi: 10.1016/j.energy.2020.118456
[8]	WEMHOFF A. Calibration of HVAC equipment PID coefficients for energy conservation[J]. Energy and Buildings, 2012, 45:60-66. doi: 10.1016/j.enbuild.2011.10.021
[9]	吕红丽, 段培永, 崔玉珍, 等. 新型模糊PID控制及在HVAC系统的应用[J]. 控制理论与应用, 2009, 26(11):1277-1281.
	LV Hongli, DUAN Peiyong, CUI Yuzhen, et al. Novel fuzzy PID control and application to HVAC systems[J]. Control Theory & Applications, 2009, 26(11):1277-1281.
[10]	ANDERSON M, BUEHNER M, YOUNG P, et al. MIMO robust control for HVAC systems[J]. IEEE Transactions on Control Systems Technology, 2008, 16(3):475-483. doi: 10.1109/TCST.2007.903392
[11]	王旭东, 吴莉萍, 戚艳, 等. 基于模型预测控制的智能楼宇暖通空调能量管理策略[J]. 电力系统及其自动化学报, 2019, 31(6):98-106.
	WANG Xudong, WU Liping, QI Yan, et al. Energy management strategy for heating,ventilation and air conditioning in smart building based on model predictive control[J]. Proceedings of the CSU-EPSA, 2019, 31(6):98-106.
[12]	刘静, 史梦鸽, 胡永锋. 含电池储能系统的智能楼宇多阶段能量管理策略[J]. 综合智慧能源, 2022, 44(3):29-37. doi: 10.3969/j.issn.2097-0706.2022.03.005
	LIU Jing, SHI Mengge, HU Yongfeng. Multi-stage energy management strategy for smart buildings with BESS[J]. Integrated Intelligent Energy, 2022, 44(3):29-37. doi: 10.3969/j.issn.2097-0706.2022.03.005
[13]	WANG J, LI S, CHEN H, et al. Data-driven model predictive control for building climate control:Three case studies on different buildings[J]. Building and Environment, 2019, 160:106204. doi: 10.1016/j.buildenv.2019.106204
[14]	YAMASHITA D Y, VECHEIU I, PGAUBERT J. Two-level hierarchical model predictive control with an optimised cost function for energy management in building microgrids[J]. Applied Energy, 2021, 285:116420. doi: 10.1016/j.apenergy.2020.116420
[15]	KUBOTH S, HEBERLE F, KONIG A, et al. Economic model predictive control of combined thermal and electric residential building energy systems[J]. Applied Energy, 2019, 240:372-385. doi: 10.1016/j.apenergy.2019.01.097
[16]	OLDEWURTEL F, JONES C N, PARISIO A, et al. stochastic model predictive control for building climate control[J]. IEEE Transactions on Control Systems Technology, 2014, 22(3):1198-1205. doi: 10.1109/TCST.2013.2272178
[17]	OSTADIJAFARI M, DUBEY A, LIU Y, et al. Smart building energy management using nonlinear economic model predictive control[C]//2019 IEEE Power & Energy Society General Meeting(PESGM). Atlanta:IEEE, 2019.
[18]	谢澜涛, 谢磊, 苏宏业. 不确定系统的鲁棒与随机模型预测控制算法比较研究[J]. 自动化学报, 2017, 43(6):969-992.
	XIE Lantao, XIE Lei, SU Hongye. A comparative study on algorithms of robust and stochastic mpc for uncertain systems[J]. Acta Automatica Sinica, 2017, 43(6):969-992.
[19]	曹子飞, 杨栋, 吴茂坤, 等. 控制器参数对AGC调节性能的影响[J]. 综合智慧能源, 2022, 44(4):36-42. doi: 10.3969/j.issn.2097-0706.2022.04.005
	CAO Zifeng, YANG Dong, WU Maokun, et al. Influence of controller parameters on AGC regulation performance[J]. Integrated Intelligent Energy, 2022, 44(4): 36-42. doi: 10.3969/j.issn.2097-0706.2022.04.005
[20]	荆立坤, 唐宜强, 潘凤萍, 等. 基于鲁棒约束的PI控制器参数多目标优化及应用[J]. 华电技术, 2021, 43(5):1-8.
	JING Likun, TANG Yiqiang, PAN Fengping, et al. Multi-objective optimization of PI controller parameters under robustness constraint and its application[J]. Huadian Technology, 2021, 43(5):1-8.
[21]	PIPPIA T, LAGO J, CONINCK R D, et al. Scenario-based nonlinear model predictive control for building heating systems[J]. Energy & Buildings, 2021, 247:111108.
[22]	Indoor environmental input parameters for design and assessment of energy performance of buildings addressing indoor air quality,thermal environment,lighting and acoustics: NF E51-762-2007[S].

控制器	J_eco
控制器	β=10	β=100	β=200	β=500
DeMPC	99.4	394.8	723.0	1707.7
SMPC	77.8	94.0	121.9	145.2
PBMPC	65.4	65.4	65.4	65.4

控制器	DV
控制器	β=10	β=100	β=200	β=500
DeMPC	6.2	6.2	6.2	6.2
SMPC	0.55	0.57	0.67	0.04
PBMPC	0	0	0	0
